Trigger 1: Select Trigger 1 from the Control menu to specify when the Trigger 1 port
outputs 12 volts. There is a three-second delay before activation to prevent operation
while selecting an aspect ratio.
• AutoScope causes the port to output 12 volts whenever the the Cinema or Virtual
Cinema aspect ratio is active.
• Lamp causes the port to output 12 volts whenever the lamp (LED RGB assembly) is
on.
• 4:3 causes the port to output 12 volts whenever the 4:3 aspect ratio is chosen. The
output stops if PIP is enabled (PIP source is set to anything other than off).
• RS232 causes the port to output 12 volts when an RS232 screen trigger 1 “on”
command is received and stop when a trigger 1 “off” command is received. The 12 volt
output also stops when the projector is turned off.
Trigger 2: Select Trigger 2 from the Control menu to configure the Trigger 2 output.
Trigger 2 operates identically to Trigger 1.
LanguageSelect Language from the Main Menu to change the OSD Language.
The Q-650i can display the menus in English, French, German, Italian, Spanish, Swedish,
Portuguese or Russian.
Press or to select a language. Then, press ENTER to confirm your selection.
