Mio Modero Device Family
Installation
The basic front and rear components of the Mio Modero are as follows:
Before touching the device, discharge the static electricity from your body by touching
a grounded metal object.
FIG. 2 Mio Modero Front and Rear Components
AxLink
3.5 mini Phoenix
connector
Notch to pry
faceplate free
(Rear Single)
Installation Button
Slot to pry
button free
8 position mini
DIP switch
Screw
holes
(Front Single)
Screw
holes
AxLink
3.5 mini Phoenix
connector
8 position mini
DIP switch
(Rear Double)
Notch to pry
faceplate free
PWR+
PWR+
