9
®
Connections to user console peripherals
To connect a keyboard and mouse
Note: The ServSwitch Secure unit can directly accommodate only a USB-style
keyboard and mouse. If required, you can use suitably shielded conversion
cables to connect peripherals that have PS/2-style interfaces.
1 Wherever possible, ensure that power is disconnected from the unit and the
host computer(s) to be connected.
2 At the far left side of the rear panel, connect the cables from the keyboard
and mouse to the USB sockets marked and respectively.
USER CONSOLE
USER CONSOLE
To connect speakers
1 Wherever possible, ensure that power is disconnected from the unit and the
host computer(s) to be connected.
2 At the far left side of the rear panel, connect the speaker cable to the socket
marked
