SPECIFICATIONS
7
Operating the DVD 8 player is a simple procedure. It is designed for long term stability in virtually
any home operating environment. However, if the unit is operated outside the parameters
outlined in this owner's manual, damage may result. Please read this manual carefully before
putting your new DVD 8 player into operation.
The following section describes the DVD 8 players’ basic specifications. The specifications are
subject to change without notice or obligation.
VIDEO SPECIFICATIONS
...........................................................................................................................................................................
Playback System DVD Video / Video CD / CD / DVD-RW / DVD+RW / CD-RW /
DVD-Audio / SACD
...........................................................................................................................................................................
Video DAC chips 12 bit/108 MHz
...........................................................................................................................................................................
Video S/N Ratio 70 dB
...........................................................................................................................................................................
Video Signal Resolution 540 TV Lines (DVD)
...........................................................................................................................................................................
Signal Format System PAL / NTSC
...........................................................................................................................................................................
Composite Video Output 1.0 volt peak to peak (75 Ohm), Sync Negative
...........................................................................................................................................................................
S-Video Luminance Signal: 1 volt peak to peak (75 Ohm load)
Color Signal: 0.286 volt peak to peak (75 Ohm load)
...........................................................................................................................................................................
Component Video Output Y Output Level: 1.0 volt peak to peak (75 Ohm load)
Pb Output Level: 0.7 volt peak to peak (75 Ohm load)
Pr Output Level: 0.7 volt peak to peak (75 Ohm load)
...........................................................................................................................................................................
AUDIO SPECIFICATIONS
...........................................................................................................................................................................
Master Clock Jitter Below measurable levels
...........................................................................................................................................................................
Digital/Analog Converters 24 bit/192 kHz Cirrus Logic 4360
...........................................................................................................................................................................
Analog Outputs RCA 5.1 & 2 channel, separate output sets
...........................................................................................................................................................................
Frequency Range 2-22 kHz Fs = 48 kHz
2-44 kHz Fs = 96 kHz
...........................................................................................................................................................................
Amplifier Linearity 0.5 dB (20 Hz – 20 kHz)
...........................................................................................................................................................................
Phase Linearity 3.0 degrees (20 Hz – 20 kHz)
...........................................................................................................................................................................
Dynamic Range 106 dB (1 kHz)
...........................................................................................................................................................................
Signal-to-Noise Ratio 106 dB (1 kHz)
...........................................................................................................................................................................
Channel Separation >95 dB (1 kHz)
...........................................................................................................................................................................
Total Harmonic Distortion 0.008% (1 kHz)
...........................................................................................................................................................................
Audio Output Level 2.0 V rms
