CONNECTIONS
CONNECTING A
AUDIO - PC OUT
VGA AUDIO - PC IN
PC
VGA
Connect the 15-pin D-SUB PC/VGA connector
from your computer to the 15-pin D-SUB PC/VGA
input on this unit using a monitor cable and an
audio cable (not included) as shown.
Make sure you connect the cable from the computer
( and ) to this unit
(and ).
9
TO PC Connector
TO AUDIO OUT jacks
CONNECTINGTHE POWER CORD
You can power your TV unit by plugging the detachable AC power cord into the AC socket on the
of the unit and into a wall AC power outlet. Check that the rated voltage of your unit matches your local
voltage. Make sure that the AC power cord is fully inserted into the unit.
back
NOTE
• Be sure the AC power cord is disconnected and
all
•Make sure that all the components are
connected
•
•
•
functions are off before making connections.
correctly.
When you are not going to use the unit for a
long period of time, disconnect the power cord.
The apparatus shall not be exposed to dripping
or splashing and that no objects filled with
liquids, such as vases, shall be placed on apparatus.
Mains plug is used as the disconnect device.
It shall remain readily operable and should not be
obstructed during intended use.
To be completely disconnected the apparatus from
supply mains, the mains plug of the apparatus shall
be disconnected from the mains socket outlet
completely.
To AC 120V wall outlet
AC IN 120V
TV REAR PANEL
TV REAR PANEL
