2
1
AV2
AV1
HDMI3
HDMI2 HDMI1
TV REAR PANEL
Connection to a Home Theater Audio System
CONNECTIONS
For BESTaudio performance
.
.
’
.
()
Connecting to a Home Theater System
Dolby Digital can deliver optimal 2 channel
stereo or surround sound with five discrete
full range channels plus a sixth channel for
a subwoofer
Enjoy optimal sound reproduction from your
system with a Dolby Digital amplifier that
incorporates a digital coaxial input Connect
an optional digital cable directly to the
television s SPDIF audio output to listen
through all inputs except VGA
The VGA does not support digital audio
How To Setup DigitalOutput*
.
•.
•
*
Press the MENU button on the remote control
Press the right arrow button to select AUDIO
Press the down arrow button to highlight
SPDIF type Raw or PCM
*NOTE: Refer to the User Manual from your home theater
equipment for recommended audio settings.
Surround Left Speaker
Surround Right Speaker
Dolby Surround
Connection Illustration
Center Channe
l
Front Left
Speaker
Front Right
Speaker
Dolby Prologic
Surround Receiver
optional digital cable
Subwoofer
10
Surround
Setup
Parental
12
6
Tim
e TV
Sound Mode
Bass
Treble
Balance
Surround
Audio Language
Standard
English
50
50
50
Off
Picture Audio
AVC
Off
MENU
Move Select Exit
SPDIF Type
RAW
