Maintenance
29
DX-15L150A11/DX19L150A11/DX-22L150A11
General
Note: If the problem is not solved by using these troubleshooting
instructions, try turning off your TV, then turning it on again.
Maintenance
Do not use your TV in areas that are too hot or too cold, because
the cabinet may warp or the screen may malfunction. Your TV
works best in temperatures that are comfortable to you.
Storage temperatures are 32° to 122°F (0° to 50°C).
Working temperatures are 41° to 104°F (5° to 40°C).
Do not place your TV in direct sunlight or near a heat source.
Cleaning the TV cabinet
Clean the cabinet with a soft, lint-free cloth. If the cabinet is especially
dirty, moisten a soft, lint-free cloth in a weak detergent solution,
squeeze the excess moisture from the cloth, then wipe the screen or
cabinet with the cloth. Use a clean cloth to dry the screen or cabinet.
Cleaning the TV screen
Clean the screen with a soft, lint-free cloth.
Specifications
Specifications subject to change without notice.
Weight and dimensions shown are approximate.
Legal notices
FCC Part 15
This device complies with Part 15 of the FCC Rules. Operation of this
product is subject to the following two conditions: (1) this device may
not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired
operation.
This equipment has been tested and found to comply within the limits
for a class B digital device, pursuant to Part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates,
uses, and can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and
on, the user is encouraged to try to correct the interference by one or
more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Problem Solution
One or more channels do
not display.
Make sure that the channels are
not blocked. For more
information, see “Setting parental
control levels” on page 21.
Make sure that the channels are
not hidden. For more information,
see “Hiding and adding channels”
on page 18.
The channel may have been
deleted from the channel list. You
can tune to the channel by
pressing the number buttons or
you can add the channel back to
the channel list. For more
information, see “Changing
channel settings” on page 18.
Password is lost. Enter 9999 to access the parental
controls, then set a new
password. For more information,
see “Setting parental controls” on
page 20.
Some settings cannot be
accessed.
If a setting is grayed, the setting is
not available in the current video
input mode.
TV cabinet creaks. When the TV is in use, the
temperature rises naturally and
may cause the cabinet to expand
or contract which can cause a
creaking noise. This is not a
malfunction.
Control buttons on the TV
do not work.
Disconnect the power cord, wait a
few seconds, then reconnect the
power cord and turn on the TV.
Make sure that the Button Lock
option is set to Off. For more
information, see “Locking control
buttons” on page 23.
Analog standard
NTSC
Digital standard
ATSC, 8-VSB, Clear-QAM
Screen
DX-15L150A11 - 15”
DX-19L150A11 - 19”
DX-22L150A11 - 22”
Channel coverage
VHF: 2 - 13
UHF: 14 - 69
CATV: Mid band - A8~A-1,A~I
Super band - J~W
Hyper band - AA~ZZ, AAA, BBB
Ultra band: 65~94, 100~135
Power source
AC 120 V ~ 60 Hz
Power consumption
15” - 42 W with TV on
19” - 45 W with TV on
22” - 62 W with TV on
<1 W in standby mode
Audio power
3 W + 3 W internal speaker
S-Video input
Y: 1 V (p-p), 75 ohm, negative sync
C: 0.286 V (p-p) (burst signal), 75 ohm
Video/audio input
Video: 1 V (p-p), 75 ohm, negative sync
Audio 500mV (rms)
Component input
Y: 1 V (p-p), 75 ohm, including sync
PR/CR: ±0.35 V (p-p), 75 ohm
PB/CB: ±0.35 V (p-p), 75 ohm
Audio: 500 mV (rms)
Suggested resolutions: 1080i, 720p,
480p, 480i
HDMI input
1 HDMI input jack
HDCP compliant
E-EDID compliant
Suggested scan rates: 1080p,1080i,
720p, 480p, 480i
VGA input
E-EDID compliant
Suggested scan rates: 640x480/60 Hz,
800x600/60 Hz, 1024x768/60 Hz,
1360x768/60 Hz
Audio input: Mini-jack for stereo
