Dynex DX-19L150A11 Flat Panel Television User Manual



TV components
5
DX-15L150A11/DX19L150A11/DX-22L150A11
4 Secure the wall-mount bracket to the back of your TV by screwing
four M4 screws (not provided) into the standoff screws you just
installed.
TV components
Accessories
Make sure the following accessories are included in the box with your
TV:
Remote control
Component video cable and audio cable L and R
•AC power cord
AAA batteries (2)
•Stand
Quick Start Guide
Standoff screws (4) for wall mounting
Front
75 mm
M4 screws
M4 screws
75 mm
100 mm
100 mm
For 15” TV only
For 19” and 22” TVs only
Item Name Description
VOL +
In TV mode, press to increase the volume.
In menu mode, press to move right or to adjust
menu settings.
VOL -
In TV mode, press to decrease the volume.
In menu mode, press to move left or to adjust
menu settings.
CH
In TV mode, press to select the next channel.
In menu mode, press to move up.
CH
In TV mode, press to select the previous
channel.
In menu mode, press to move down.
MENU
Press to open the on-screen menu.
INPUT
Press to open the INPUT SOURCE menu. For
more information, see “Selecting the video
input source” on page 13.
(power)
Press to turn on the TV or put the TV in standby
mode.
Caution: The TV continues to receive power
even in standby mode. Unplug the power cord
to disconnect power.
1
2
3
5
6
4
7
2
1
3
4
6
5
7
