Dynex DX-32L152A11 Flat Panel Television User Manual



10
Turning on your TV for the first timeDX-32L152A11
Connecting a home theater system
Connecting using a digital audio cable
To connect using a digital optical cable:
1 Make sure that your TV’s power cord is unplugged and the home
theater system is turned off.
2 Connect one end of a digital coaxial audio cable (not included) to
the DIGITAL AUDIO OUT jack on the back of the TV.
3 Connect the other end of the audio cable to the digital coaxial
input jack on the home theater system.
Note: The DIGITAL OUTPUT jack only works with digital TV channels.
To play TV sound through a home theater system:
1 Turn on the TV and select a program to watch.
2 Turn on the home theater system and select the TV sound source,
then adjust the volume to a comfortable level.
Connecting headphones
Warning: When using headphones, adjust the headphone volume to
avoid excessively loud volume which can damage your hearing.
To connect headphones:
Plug the headphones (not included) into the (headphone)
jack on the back of the TV.
Note: The TV sound automatically mutes when headphones are
connected.
Turning on your TV for the first
time
To configure your TV:
1 Make sure that you have inserted the batteries in the remote
control, connected your devices to the TV, and connected the AC
power.
2 Press (Power), then wait several seconds. The Initial Setup
screen opens (only the first time you turn on your TV). Follow the
prompts to complete the setup.
3 Press or to select the menu language you want, then press
ENTER. The Picture Mode screen opens.
4 Press or to select the Home Mode or Retail Mode, then
press ENTER. Home Mode reduces the TV’s total power
consumption. The Tuner Mode screen opens.
5 Press or to highlight Antenna, Cable, or Satellite Box,
depending on the type of connection you have, then press
ENTER. The Channel screen opens.
If you are using an antenna for a standard or HD TV signal or
if your cable TV is connected directly to the TV (without a
box), select Antenna.
If a cable is connected to your TV, select Cable.
If your TV is connected to a cable/satellite box, select
Cable/Satellite Box.
DIGITAL AUDIO
OUT
Back of TV
Home theater
system
Digital coaxial cable
PC/DVI AUDIO IN VGA
Sutup
ENTER
Select
Choose your menu Language
Select
Setup Wizard Language
ENTER Next
English
Espanõl
Français
Sutup
OSD Language English
Screen Mode Normal
DPMS ON
Time Setup
Caption
Reset Default
ENTER
Enter
Select
Choose your picture Mode
Select
Setup Wizard Picture Mode
ENTER Next Back
Home mode
Retail mode
Sutup
OSD Language English
Screen Mode Normal
DPMS ON
Time Setup
Caption
Reset Default
ENTER
Enter
Select
Choose your Tuner Mode
Select
Setup Wizard Tuner Mode
ENTER Next Back
Antenna
Cable
Cable/Satelite Box
