Features
Remote control
Using the remote control
To use the remote control:
• Point the remote control towards the remote sensor on the front
of your TV.
Notes:
Do not expose the remote control to shock or liquids.
Do not use the remote control in an area with high humidity.
Do not place the remote control in direct sunlight.
Do not place objects, such as furniture, between the remote control and
the remote sensor.
The remote control may not work if direct sunlight or bright light shines on
the remote sensor. Either move your TV or change the angle at which
you use the remote control.
# Button Description
1
POWER
Press to turn on your TV or put it
into Standby mode.
2 INPUT Press to cycle through the
available input sources.
3 DISPLAY Press to display status
information.
4 VIDEO Press to toggle between S-Video
and composite source modes.
5Number
buttons
Press to enter channel numbers.
In the on-screen menu, press to
enter your parental control
password.
6 – Use with the 0-9 number buttons
and ENTER button to select
digital channels.
7 VOL + Press to increase the volume.
8 MUTE Press to mute the sound. Press
again to restore the sound.
9 VOL – Press to decrease the volume.
10 MENU Press to open the on-screen
menu.
11 Press to move down, up, left, or
right in the on-screen menu.
12 ENTER Press to confirm changes or to
turn options on and off in the
on-screen menu.
INPUT
VIDEO COMP
MUTE
FAVORITE
MENU
P-LOCK MTS/SAP CCD
ZOOM
PICTURE AUDIO
SLEEP
FREEZE
EXIT
TV
DISPLAY
POWER
123
456
0
ENTER
RECALL
VOL
VOL
CH
CH
HDMI
789
1
2
3
5
6
7
8
4
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
ZRC-1
02
13 P.LOCK Press to activate or deactivate
parental controls. See “Setting
parental controls” on page 10 for
information on setting up
parental controls.
14 ZOOM Press to select the display aspect
ratio.
15 MTS/SAP In NTSC mode, press to select one
of the preset audio modes. You
can select MONO, STEREO, or
SAP (secondary audio program).
In ATSC mode, press to select the
audio language.
16 PICTURE Press to select the Brightness or
Contrast setting. You can adjust
these settings without opening
the on-screen menu.
17 SLEEP Press to set the sleep timer. For
more information, see “Setting
the sleep timer” on page 10.
18 COMP Press to select the component
source mode.
19 TV Press to select the ATSC (digital),
or NTSC (analog) TV source.
20 HDMI Press to select the HDMI mode.
21
RECALL
Press to watch the previous
channel.
22
CH
Press to tune to the next higher
channel in the channel list.
23
CH
Press to tune to the next lower
channel in the channel list.
24 FAVORITE Press to toggle the
Favorite/Normal mode. See
“Setting up the channel list” on
page 9 for more information.
25 EXIT Press to close the on-screen
menu.
26 CCD Press to turn closed captions on
and off. For more information, see
“Viewing closed captions” on
page 10.
27 FREEZE Press to freeze the video image.
Press again to unfreeze the
image. Do not freeze the video
image for long periods of time.
You may damage the TV screen.
28 AUDIO Press to select the bass or treble
setting. You can adjust these
settings without opening the
on-screen menu.
#Button Description
