SWITCHING ANALOG MODE / DIGITAL MODE
You can easily switch the TV (NTSC) and DTV
(ATSC) with the remote control and enjoy viewing the
High Definition TV programs as well as the Standard
Definition TV programs with simple operation.
1
Press [DTV/TV] on the remote control.
• The analog mode and digital mode switch alter-
nately.
• When you press
[DTV/TV] in external input,
the analog mode and digital mode will be
switched.
NOTE:
When you switch the analog mode to the digital mode, it may
take a while until the digital channel selection is completed.
The following screen is displayed while switching the mode.
INFO
CH
CH
VOL VOL
POWER
CHANNEL
RECALL
AUDIO
–
/ENT
321
654
98
+
100
0
7
DTV
/
TV
DTV/ TV
CHANNEL SELECTION
You can select the channel by using either [CH
K
/
L
]
or [the Number buttons].How to select the channel
in each way is shown below.
1 Using [CH
K
/
L
].
• Using [CH
K
/
L
], change the channel.
• When you press
[CHANNEL RECALL], the
previously selected channel will be selected.
• Same operation is available with [CHANNEL
K
/
L
] on the front panel of the main unit.
2 Using [the Number buttons].
• When you select a channel from 1 to 99, press
the channel number you want to view with
[the Number buttons]. The selected channel
will be displayed.
• When you select a channel larger than 100, press
[+100] first. Then use [the Number buttons] to
press the lower 2 digits.
• To search the minor channel of the major chan-
nel currently viewed in DTV, press
[+100]. If you
know the minor channel while viewing the major
channel with 1-digit channel number, press the
major channel number and press
[-/ENT]. Then,
press the minor channel number you want to
view. In case the major channel number is 2
digits, press the major channel number and
press the minor channel number directly. If you
press
[-/ENT] after pressing the 2-digit major
channel number, the smallest minor channel will
be selected.
• When you press
[CHANNEL RECALL], the
previously selected channel will be selected.
NOTE:
In the DTV broadcasting, one channel sometimes broadcasts
multiple programs depending on the air time. In this case, the
main channel is called major channel and the sub channel is
called minor channel.
INFO
CH
CH
VOL VOL
CHANNEL
RECALL
AUDIO
—
/ENT
INPUT
SELECT
321
654
98
+
100
0
7
MUTE
SLEEP
MENU
CHANNEL
RECALL
Number
buttons
-/ENT
CH
K
/
L
+100
NOW SCANNING
WATCHING TV
