S
PECIFICATIONS
GENERAL SPECIFICATIONS
Television system: ATSC
NTSC-M
TV Standard
Closed Caption
System: §15.119/FCC (Analog CC)
§15.122/FCC (Digital CC)
Channel coverage
VHF: 2 ~ 13
UHF: 14 ~ 69
DTV: 2 ~ 69
CATV: 2 ~ 13, A ~ W,
W+1 ~ W+84,
A-5 ~ A-1, 5A
Tuning System: Channel frequency
synthesized tuning system
Channel access: Direct access keyboard,
programmable
scan and up/down
Terminals
Antenna input: VHF/UHF/DTV/CATV
75 ohm unbalanced
(F-type)
S-Video input: Mini DIN 4-pin jack
Video input: RCA connector x 2
(1 x Front / 1 x Rear)
Audio input: RCA connector x 4
(2 (L/R) x Front / 2 (L/R) x Rear)
Coaxial digital audio output:
One pin jack, 500mVpp (75 ohm)
Component Video/Audio input
One pin jack (Y) / 1Vpp (75 ohm)
Two pin jacks (Cb/Cr) / 700mVpp (75 ohm)
RCA connector x 2 (L/R)
Stereo Sound System
2 speakers
ELECTRICAL SPECIFICATIONS
Sound output: 2W, 8 ohm x 2
OTHER SPECIFICATIONS
Remote control: Digital encoded
infrared light system
Operating
temperature: 5°C to 40°C
(41°F to 104°F)
Power requirements: AC120V, 60Hz
Power consumption
(Maximum): 140W
Picture tube: 32"
Dimensions: H : 26.2" (665mm)
W:33.4" (849mm)
D:21.3" (540mm)
Weight: 112.6 lbs. (51.0kg)
MISCELLANEOUS / SPECIFICATIONS
• Designs and specifications are subject to change without notice and without our legal obligation.
• If there is a discrepancy between languages, the default language will be English.
