INITIAL SETTINGS (cont.)
Setting clock semiautomatically
— Semiauto Clock Set
You can change the host channel/D.S.T. /time zone
setting manually.
First follow steps A to B on page 17, then go to the
following steps.
C Access Auto Clock Set screen
Then;
To select the host channel — go to step D.
To select the D.S.T. mode — go to step E.
To select the time zone — go to step F.
NOTE:
The time set previously will be erased when “AUTO
CLOCK SET” is selected.
D Select host channel
NOTE:
Some PBS channels do not transmit clock setting data.
E Select D.S.T. mode
You have three choices:
“AUTO”– Select if you want to adjust your VCR’s
clock automatically by the incoming
signal from the host channel. (Auto
Daylight Saving Time*)
“ON”– Adjustment will be made by the built-
in clock itself.
“OFF”– Select when Daylight Saving Time
does not apply to you.
Press [FG] to move the arrow to “D.S.T.”, then
press [D E] repeatedly until the desired setting is
selected.
F Select time zone
Press [FG] to move the arrow to “TIME ZONE”,
press [D E] repeatedly until “AUTO” or the
desired time zone is selected.
Each time you press the button, the time zone
changes as follows:
U“AUTO” U “ATLANTIC” U “EASTERN”
U “CENTRAL” U “MOUNTAIN” U “PACIFIC”
U “ALASKA” U “HAWAII” U (back to the
beginning)
NOTE:
If an incorrect clock time is displayed by the Plug & Play
setting, you may be receiving the clock setting data of a
PBS channel from an adjacent time zone or from an
incorrect PBS channel from a cable TV system. If you
selected “AUTO” for the host channel in step D, be
sure to select the correct time zone manually.
G Return to normal screen
Press [MENU].
Press [FG] to move
the arrow to “AUTO
CLOCK SET”, then
press [OK].
You can either select
“AUTO” or enter a
PBS channel number.
Press [FG] to move
the arrow to “HOST
CH”, then press [D
E] until “AUTO” or
the desired PBS
channel number is
selected.
* Auto Daylight Saving Time
This function enables automatic adjustment of the VCR’s
clock at the start and end of Daylight Saving Time.
With Auto DST activated, . . .
. . . on the first Sunday of April at 2:00 AM, the clock is
adjusted to 3:00 AM.
. . . on the last Sunday of October at 2:00 AM, the clock is
adjusted to 1:00 AM.
FUNCTION SET UP
INITIAL SET UPTUNER SET UP
THEN PRESS [OK]
CLOCK SET
AUTO CLOCK SET
MANUAL CLOCK SET
AUTO CLOCK ON
GUIDE CHANNEL OTHER
SELECT WITH ARROW KEYS
SELECT
OK
EXIT
MENU
FUNCTION SET UP
INITIAL SET UPTUNER SET UP
THEN PRESS [OK]
HOST CH [TV]
D.S.T AUTO
AUTO
AUTO
TIME ZONE
RETURN
AUTO CLOCK SET TIME AM DATE 1/1 (THU) 2004
SELECT WITH ARROW KEYS
SELECT
OK
EXIT
MENU
:
IMPORTANT:
Turn off the VCR after performing Semiauto Clock Set.
[AUTO] will appear on the front display panel while the
clock is being set. The current clock time will appear
automatically when the clock setting is complete.
