JVC HR-S7900U VCR User Manual



EN
19
Turn on the VCR and the TV, and select the VCR
channel 3 or 4 (or AV mode) on the TV.
INITIAL SET
CLOCK SET
LANGUAGE ENGLISH
GUIDE CHANNEL SET
CABLE BOX SET
=
DBS RECEIVER SET
SELECT WITH (5,) AND (OK)
PRESS (MENU) TO END
DBS RECEIVER SET
OFF
PRESS (5,), THEN (OK)
PRESS (MENU) TO END
2
Access Main Menu screen on VCR
Press MENU.
3
Access Initial Set screen
Press SHUTTLE PLUS %fi to move the highlight
bar (arrow) to “INITIAL SET”, then press OK or
SHUTTLE PLUS
#
.
4
Access DBS Receiver Set screen
Press SHUTTLE PLUS
%fi to move the
highlight bar (arrow) to
“DBS RECEIVER SET”,
then press OK or
SHUTTLE PLUS
#
.
5
Select DBS receiver output channel
Your selection depends
on how your DBS
receiver is connected to
your VCR.
If your DBS receiver
is connected to your
VCR’s ANTENNA IN
terminal on the rear
Press SHUTTLE PLUS %fi on the Remote until
the channel number representing the DBS
receiver’s output (CH3 or CH4) appears on the
screen.
If your DBS receiver is connected to your VCR’s
AUDIO/VIDEO IN connectors on the front panel
Press SHUTTLE PLUS %fi on the Remote until
“ON F-1 (FRONT)” appears on the screen.
If your DBS receiver is connected to your VCR’s
AUDIO/VIDEO IN connectors on the rear panel
Press SHUTTLE PLUS %fi on the Remote until
“ON L-1 (REAR)” appears on the screen.
If you do not use a DBS receiver
Press SHUTTLE PLUS %fi on the Remote until
“OFF” appears on the screen.
CONTINUED ON NEXT PAGE \
123
456
7
89
0
2
4
1
3
2
3 4
3 5
Setting DBS receiver output
channel & brand
After installation, set the DBS receiver’s output channel
and its brand correctly; otherwise, the Controller cannot
work correctly.
1
Turn on DBS receiver
Select a channel other than channel 55, 100 or
205 on your DBS receiver.
