JVC HR-S9500U VCR User Manual



EN 51
123
456
7
89
0
2
4
1
3
OK
NUMBER "9"
NUMBER "8"
TIMER
NUMBER "7"
SP/EP
SET TAPE SPEED
8
Press SP/EP to set the tape speed.
RETURN TO NORMAL
SCREEN
9
Press PROG. or OK. "PROGRAM COMPLETED"
appears on the screen for about 5 seconds, then normal
screen appears.
ENGAGE TIMER MODE
10
Press TIMER. The VCR turns off automatically and ""
is displayed on the display panel.
PROG.
To Timer-Record Weekly Or Daily Serials . . .
. . . anytime during steps 3 through 9, press WEEKLY (NUMBER
key “9”) for weekly serials or DAILY (NUMBER key “8”) for
daily serials (Monday–Friday). Either "WEEKLY" or "DAILY"
appears on the screen. Pressing the button again makes the
corresponding indication disappear.
NOTES:
To disengage the timer before recording starts, press TIMER
again. Pressing once more re-engages it.
In case of a power failure after programming, the VCR’s memory
backup keeps your selections for approximately 10 minutes.
Programs that start after midnight must have the next day’s date.
After timer recording is completed, the VCR’s power goes off
automatically.
You can program the timer while a regular recording is in
progress; the on-screen menu will not be recorded.
If the end of tape is reached during timer recording, the
cassette is automatically ejected.
When timer-recording cable or satellite channels through an
external tuner, be sure to keep the cable box or satellite
receiver's power ON.
10:00
11:00
12:00
ATTENTION
If there is a conflict in the timer schedule and one program
overlaps with another, only the parts shown below in gray
will be recorded.
Pattern 1: The program with the lower program number
will be recorded.
Pattern 2: The program that is broadcast earlier will be
recorded.
Pattern 3: The program that is broadcast earlier will be
recorded, followed by the remaining portion of
the other program.
CH10
CH40 Not recorded
Program 1
Program 2
10:00
11:00
12:00
CH10
Program 2
Not recorded
Program 1
CH40
10:00
11:00
12:00
CH10
CH40
Program 1
Program 2
Not recorded
ATTENTION FOR DBS RECEIVER USERS
If you are using a DBS receiver
(unless "DBS RECEIVER SET" is
set to "OFF" pg. 20), the
BAND indication (TV or CATV
or DBS) appears under the
channel number display. If the
channel number that has been
entered requires that the band
be set, "7=DBS" is displayed
on the screen. Press the NUMBER key "7" to select the
desired band.
a– TV :To timer-record a regular TV program received
on the VCR.
b– CATV : To timer-record a cable TV program received on
the VCR, or through a cable box (unless "CABLE
BOX SET" is set to "OFF"
pg.17).
c– DBS : To timer-record a satellite program received
through a DBS receiver.
If "BAND" is set to "TV" at the Tuner Set screen ( pg.14)
and "CABLE BOX SET" is set to "OFF" at the Cable Box
Set screen (pg. 17), CATV will not be displayed on the
Program screen; If "BAND" is set to "CATV" or "CABLE
BOX SET" is set to "ON", TV will not be displayed.
PROGRAM 1
START STOP
8:00AM = 9:00PM
DATE CH
12/24/98 110 SP
THU DBS
PRESS (+/–, SP/EP, 8=DAILY,
9=WEEKLY, 7=DBS), THEN (0K)
PRESS (PROG.) TO END
