Technical Specification
UNIDISK SC PLAYER
Owner’s Manual
English
32
Technical Specification
Power consumption 40 W approx
Physical
Weight 4.3 kg
Dimensions 380 (W) x 360 (D) x 80 (H) mm
Video outputs
Type Connector Level Impedance Notes
SCART version
Component SCART RGB + Composite: 75 Ω
1 Vp-p
Composite SCART 1 Vp-p 75
Ω
S-video 4 pin mini-DIN Y (lum): 1 Vp-p 75 Ω
C (chr): 700 mVp-p
Phono version
Component 3 x RCA YPrPb 75 Ω
S-video 4 Pin mini-DIN Y (lum): 1 Vp-p 75 Ω
C (chr): 700 mVp-p
Composite 1 x RCA 1 Vp-p 75
Ω
Video inputs
Type Connector Level Impedance Notes
SCART version
Component SCART
S-video 4 pin mini-DIN
Phono version
Component 3 x RCA
S-video 4 pin mini-DIN
Composite 1 x RCA
–
–
–
–
–––
–––
–––
–––
–––
–
–
Electrical
Mains voltage 100-230 Vac @ 50-60 Hz
Audio outputs
Type Connector Level Impedance Notes
SCART version
Unbalanced 6 x RCA 2 Vrms 300 Ω Pre-amp out
Line level 2 x RCA Fixed out
Digital 1 x SPDIF 500 mVp-p 75
Ω
1 x TOSLINK
Phono version
Unbalanced 6 x RCA 2 Vrms 300 Ω Pre-amp out
Line level 2 x RCA Fixed out
Digital 1 x SPDIF 500 mVp-p 75
Ω
1 x TOSLINK
Audio inputs
Type Connector Level Impedance Notes
SCART version
Unbalanced 4 x RCA 2 x stereo
Unbalanced TV SCART Stereo
Unbalanced VCR SCART Stereo
Digital 2 x SPDIF
2 x TOSLINK
Phono version
Unbalanced 4 x RCA 2 Vrms 300 Ω
Digital 2 x SPDIF 500 mVp-p 75 Ω
2 x TOSLINK
Data and control
Type Connector Level Impedance Notes
RS232 2 x RJ11
Remote in/out 2 x RCA 4 mA
For KNEKT use only
IR flasher 2 x 3 mm jack
Accessory socket 1 x RJ45
KNEKT control 5 x RJ45
–
–
–
–––
–––
––
–
––
–––
––
––
––
––
––
–
––
–
–
–
–
–
––
–
––
–
–
