Loading the Batteries
FUNCTIONAL OVERVIEW
Display
Displays During Operation
Stays on when the inserted
disc is being played back.
CD:
Lights up when a CD is inserted
into the tray.
VCD:
Lights up when a Video CD is
inserted into the tray.
Lights up when a DVD is
inserted into the tray.
Lights up when the
inserted disc comes
to a pause.
Stays on when repeat chapter function is on.
Stays on when repeat track function is on.
Stays on when
the A-B repeat
function is on.
Stays on when
the repeat function is on.
Stays on when repeat
title function is on.
Displays how long a current title or track has been
played back. When a chapter or track has switched,
the number of a new title, chapter or track is displayed.
Lights up when a
playback control
is activated.
Power on
No disc inserted
Tray open
Tray closed
Loading the Disc
Power off
1. Open the battery compartment cover.
2. Insert two “AA” (R6P) batteries, with each
one oriented correctly.
3. Close the cover.
NOTES
• Do not mix alkaline and manganese batteries.
• Do not mix old and new batteries.
Cautions On Batteries
• Use “AA” (R6P) batteries in this remote control unit.
• Replace the batteries with new ones approximately
once a year, though this depends on the frequency
with which the remote control unit is used.
• If the remote control unit does not operate from
close to the main unit, replace the batteries with
new ones, even if less then a year has passed.
• The included battery is only for verifying operation.
Replace it with a new battery as soon as possible.
• When inserting the batteries, be careful to do so in
the proper direction, following the and marks
in the remote control unit’s battery compartment.
• To prevent damage or battery fluid leakage:
• Do not use a new battery with an old one.
• Do not use two different types of batteries.
• Do not short-circuit, disassemble, heat or dispose
of batteries in flames.
• Remove the batteries when not planning to use the
remote control unit for a long period of time.
• If the batteries should leak, carefully wipe off the
fluid from the inside of the battery compartment,
then insert new batteries.
Using the remote control
Keep in mind the following when using the remote
control:
• Make sure that there is no obstacle between the
remote and the remote sensor on the unit.
• Use within the operating range and angle, as shown.
Within about 17 ft (about 5 m)
/
