DVD Setup Menu
45
English
HDMI VIDEO
• Default setting: AUTO
Selects a suitable video resolution depending on the capability of the connected TV/device to
enhance the HDMI video output.
• 480P – Progressive output in 480 lines for NTSC TV
• 576P – Progressive output in 576 lines for PAL TV
• 720P – Progressive output upscaled to 720 lines
• 1080i – Interlaced output upscaled to 1080 lines
• 1080P – Progressive output upscaled to 1080 lines
• AUTO – The video output will automatically follow the display’s supported resolution
Note
• If no display appears on the TV due to an unsupported resolution, use the composite video cable to connect the
DVD system and your TV. Turn on your TV to the correct input channel for the composite video and adjust the
resolution setting to 480P/576P.
• The resolution can also be set with the HDMI button on the front panel.
• In general, the larger the number, the higher the resolution.
• When the resolution is changed, the image may be corrupted or the output may take longer than normal.
• Pressing the HDMI button for three seconds or more toggle the HDMI on/off state (see pages 13, 14).
• 720P/1080i/1080P only supports 60 Hz Video signal.
Setup Examples
Resolution
(HDMI Setting)
Playback Disc
Disc Recorded in Squeeze Ratio Disc Recorded in 4:3 Ratio
TV ASPECT Monitor Setting TV ASPECT Monitor Setting
480P
576P
16:9 WIDE
Full/Squeeze
SUPERWIDE
16:9 SQUEEZE
OFF
*1
Standard
Normal
4:3
Through
720P
1080i
10 80P
Normal/Through
AUTO
The resolution is automatically selected to match the monitor you are using. Set TV SYSTEM, PSCAN
FORMAT and your monitor setting to match the selected resolution.
Some monitors may use setting names that are different than those shown here.
*1
If the aspect ratio you desire is not available, select the most suitable setting from SUPERWIDE, 16:9 SQUEEZE and
OFF in “PSCAN FORMAT”.
Video Out format when HDMI is activated
HDMI Video
Output
YCbCr Output
Video/S-Video output
Progressive ON Progressive OFF
480P 480P (NTSC progressive)
Follow the Disc Source with Interlace.
(ex: NTSC disc play: NTSC interlace)
576P 576P (PAL progressive)
720P
10 80i
1080P
No Video
