SACD/CD
1 Press MENU during play.
2 Using the navigation arrows select either SACD or CD
3 Press the navigation arrows repeatedly until the desired track is selected, then press ENTER.
VCD
1 Press AUDIO during play.
2 Press AUDIO repeatedly until the desired sound is selected.
DVD
1 Press AUDIO during play. Number of the audio soundtrack language being played back.
2 Press AUDIO repeatedly until the desired language (or encoding method, channel number) is selected.
NOTES
• When the desired language is not selected even after pressing the button several times, it means that
the language is not available on the disc.
• When the power is turned on or the disc is removed, the language heard is the one selected at the
initial settings. If this language is not recorded on the disc, only the available language on the disc will
be heard.
• Some discs may not respond to Audio feature.
CONNECTING TO A MULTI-CHANNEL SOUND SYSTEM (SACD/DVD-A)
Connect the audio outputs to your integrated amplifier as shown below. Then set up the speaker bass
response and configuration as per the 5.1 SPEAKER SETUP.
DOLBY DIGITAL SOUND
PLAYBACK AUDIO WITH CD, VCD, SACD, AND DVD
Operation
FRONT
L
R
SURR
L
R
SURR- B
L
EXTERNAL7.1 INPUT
R
CENTER
SUBW
Rear of M15 A/V Surround Sound
Preamplifie r 7.1 Inputs
0 dB
Center
Size
Level
Return
Distance
Test
RR
Large
1 ft/0.3m
100 Hz
Xover Freq.
OFF
Digital Audio
Output
5.1 Speaker
Setup
DRC
Test Tone
Master Volume
Downmix
