One can enjoy the high quality dynamic sound of Dolby Digital, Dolby Pro Logic and 2 Channel Digital Stereo.
ABOUT DOLBY DIGITAL SOUND
Dolby Digital is the surround sound technology used in theatres showing the latest movies, and is now available to reproduce this realistic effect in
the home. You can enjoy motion picture and live concert DVD video discs by connecting the M55 to a 5.1 channel A/V receiver equipped with a
Dolby Digital decoder (AC-3) or Dolby Digital processor.
CONNECTING TO A SURROUND SOUND SYSTEM
Setup
From DIGITAL OUT jack
(COAXIAL or OPTICAL)
75 ohm coaxial cable or
optical cable
From S-VIDEO / Component Video /
Composite or SCART
S-VIDEO / Component / Composite
75–Ohm coaxial or SCART cable
To digital input jack of surround
receiver equipped with Dolby Digital
decoder (coaxial or optical).
To S-Video / Component / Composite
or SCART inputs of receiver.
Connection example
Front speaker
(left)
To S-video input or
Video input
Centre
speaker
Front speaker
(right)
Subwoofer
Rear Speaker
(right surround)
Rear speaker
(left surround)
TO ENJOY DOLBY DIGITAL SOUND
You need to select from the OSD drop down menu of the M55, Audio, ‘Dolby Digital/PCM’ and ‘Sample Freq.’, ‘96 kHz’ or ‘48 kHz’. If uncertain,
leave the default ‘Stream/PCM’ and ‘48 kHz’ from the menu. Do not connect the Digital Audio Output of this DVD player to your receiver unless
you are connecting the DIGITAL OUT jack of this DVD player to an AV decoder that has the Dolby Digital or DTS decoding function. High volume
sound may damage your hearing as well as the speakers (Refer to Selecting Digital Audio Output. (Refer to Initial Setup Settings, Audio)
NOTE
Refer to the owner’s manual of your audio equipment as well. Depending on your Dolby Digital surround sound decoder, the decode rate may
be 96 kHz or 48 kHz. When you connect the M55 to other equipment, be sure to turn off the power and unplug all of the equipment from the
wall outlet before making any connections. The output sound of the M55 has a wide dynamic range. Be sure to adjust the receiver’s volume to
a moderate listening level. Otherwise, the speakers may be damaged by a sudden high volume sound. Turn off the receiver before you connect
or disconnect the M55’s power cord. If you leave the receiver power on, the speakers may be damaged.
To enjoy Dolby Digital sound from
this DVD player you need the
following:
• DVD recorded in Dolby Digital
surround format.
• 5.1-channel receiver equipped
with a Dolby Digital decoder,
or a Dolby Digital processor
and power amplifier.
• 5 speakers and 1 sub woofer
