CONNECTING TO A TV DIRECTLY
NOTE
75-Ohm video and audio cables are supplied with the M55. SCART and S-Video cables can be purchased from your local NAD retailer.
WARNING
Do not connect the Digital Audio Output of this DVD player unless you are connecting the DIGITAL OUT jack of this DVD player to a TV that is
equipped with an AV decoder that has the Dolby Digital decoding function. High volume sound may damage your hearing as well as the speakers.
(Refer to Initial Setup Settings, Audio)F
NOTES
• Refer to the owner’s manual of your receiver as well.
• Before you connect the M55 to other equipment, be sure to turn off the power and unplug all of the equipment from the wall outlet before
making any connections.
• Depending on your Digital sound decoder, the decode rate may be 96 kHz or 48 kHz.
• The output sound of the M55 has a wide dynamic range. Be sure to adjust the receiver’s volume to a moderate listening level. Otherwise, the
speakers may be damaged by a sudden high volume sound.
• Turn off the receiver before you connect or disconnect the M55’s power cord. If you leave the receiver power on, the speakers may be damaged.
S-VIDEO of the M55 to the
S-Video of the TV
Composite VIDEO
OUT Jack of the M55
to the composite
video of the TV
SCART/RGB OUT Jack of the
M55 (EURO version) to the 21-
pin SCART of the TV
COMPONENT VIDEO
OUT Jacks of the M55
to the component video
of the TV
TV or monitor with
audio/video inputs
