DOLBY DIGITAL SOUND
One can enjoy the high quality dynamic sound of Dolby Digital, Dolby Pro Logic and 2 Channel Digital Stereo.
ABOUT DOLBY DIGITAL SOUND
Dolby Digital is the surround sound technology used in theatres showing the latest movies, and is now available to reproduce this realistic effect in
the home. You can enjoy motion picture and live concert DVD video discs by connecting the T585 to a 5.1 channel A/V receiver equipped with a
Dolby Digital decoder (AC-3) or Dolby Digital processor.
CONNECTING TO A SURROUND SOUND SYSTEM
Setup
From DIGITAL OUT jack
(COAXIAL or OPTICAL)
75 ohm coaxial cable or
optical cable
From S-VIDEO / Component Video /
Composite or SCART
S-VIDEO / Component / Composite
75–Ohm coaxial or SCART cable
To digital input jack of surround
receiver equipped with Dolby
Digital decoder (coaxial or digital).
To S-Video / Component / Composite
or SCART inputs of receiver.
Connection example
Front speaker
(left)
To S-video input or
Video input
Centre
speaker
Front speaker
(right)
Subwoofer
Rear Speaker
(right surround)
Rear speaker
(left surround)
TO ENJOY DOLBY DIGITAL SOUND
You need to select from the OSD drop down menu of the T585, Audio, ‘Dolby Digital/PCM’ and ‘Sample Freq.’, ‘96 kHz’ or ‘48 kHz’. If uncertain,
leave the default ‘Steam/PCM’ and ‘48 kHz’ from the menu. Do not connect the Digital Audio Output of this DVD player to your receiver unless you
are connecting the DIGITAL OUT jack of this DVD player to an AV decoder that has the Dolby Digital or DTS decoding function. High volume sound
may damage your hearing as well as the speakers (Refer to Selecting Digital Audio Output. (Refer to Initial Setup Settings, Audio).
NOTE
Refer to the owner’s manual of your audio equipment as well. Depending on your Dolby Digital surround sound decoder, the decode rate may
be 96 or 48K. When you connect the T585 to other equipment, be sure to turn off the power and unplug all of the equipment from the wall
outlet before making any connections. The output sound of the T585 has a wide dynamic range. Be sure to adjust the receiver’s volume to a
moderate listening level. Otherwise, the speakers may be damaged by a sudden high volume sound. Turn off the receiver before you connect or
disconnect the T585’s power cord. If you leave the receiver power on, the speakers may be damaged.
To enjoy Dolby Digital sound from
this DVD player you need the
following:
• DVD recorded in Dolby Digital
surround format.
• 5.1-channel receiver equipped
with a Dolby Digital decoder,
or a Dolby Digital processor
and power amplifier.
• 5 speakers and 1 sub woofer
T585 Safety.qxd 3/23/2006 4:12 PM Page 20
