En-12
Main menu Sub menu Sub menu 2 Sub menu 3 Sub menu 4 RESET
REFERENCE
PICTURE CONTRAST מ←→ם 0←52→72 YES En-20
BRIGHTNESS מ←→ם 0←32→64 YES En-20
SHARPNESS מ←→ם 0←16→32 YES En-20
COLOR מ←→ם 0←32→64 YES En-20
TINT R←→G 0←32→64 YES En-20
PICTURE MODE BRIGHT/NORMAL/THEAT.1/THEAT.2/DEFAULT YES En-20
NR OFF/NR-1/NR-2/NR-3 YES En-20
COLOR TEMP. LOW/MID LOW/MID/HIGH YES En-20
WHITE BALANCE GAIN RED מ←→ם 0←40→70 YES En-21
GAIN GREEN מ←→ם 0←40→70 YES En-21
GAIN BLUE מ←→ם 0←40→70 YES En-21
BIAS RED מ←→ם 0←40→70 YES En-21
BIAS GREEN מ←→ם 0←40→70 YES En-21
BIAS BLUE מ←→ם 0←40→70 YES En-21
RESET OFF←→ON YES En-21
GAMMA 1←→2←
…
→4 YES En-21
LOW TONE *
3
AUTO←→1←
…
→3 YES En-21
COLOR TUNE RED Y←→M0←32→64 YES En-21
GREEN C←→Y0←32→64 YES En-21
BLUE M←→C0←32→64 YES En-21
YELLOW G←→R0←32→64 YES En-21
MAGENTA R←→B0←32→64 YES En-21
CYAN B←→G0←32→64 YES En-21
RESET OFF←→ON YES En-21
Main menu Sub menu Sub menu 2 Sub menu 3 Sub menu 4 RESET
REFERENCE
AUDIO BASS מ←→ם 0←13→26 YES En-22
TREBLE מ←→ם 0←13→26 YES En-22
BALANCE L←→R -22←0→+22 YES En-22
AUDIO INPUT1 VIDEO 1-3 / HD/DVD 1-2 / RGB 1-3 YES En-22
AUDIO INPUT2 VIDEO 1-3 / HD/DVD 1-2 / RGB 1-3 YES En-22
AUDIO INPUT3 VIDEO 1-3 / HD/DVD 1-2 / RGB 1-3 YES En-22
Main menu Sub menu Sub menu 2 Sub menu 3 Sub menu 4 RESET
REFERENCE
IMAGE ADJUST ASPECT MODE NORMAL/FULL/STADIUM/ZOOM/2.35:1/14:9/TRUE*
3
— En-22
V-POSITION מ←→ם -64←0→+64 YES En-22
H-POSITION מ←→ם -128←0→+127 YES En-22
V-HEIGHT מ←→ם 0←→64 YES En-22
H-WIDTH מ←→ם 0←→64 YES En-22
AUTO PICTURE OFF←→ON*
2
NO En-22
FINE PICTURE*
1
מ←→ם*
2
0←→64 YES En-22
PICTURE ADJ.*
1
מ←→ם*
2
0←→128 YES En-22
Main menu Sub menu Sub menu 2 Sub menu 3 Sub menu 4 RESET
REFERENCE
OPTION1 OSM DISPLAY OSM OFF←→ON YES En-23
OSM ADJ. 1←
…
→6 YES En-23
OSM ANGLE H←→V YES En-23
OSM ORBITER OFF←→ON YES En-23
OSM CONTRAST LOW←→NORMAL YES En-23
BNC INPUT RGB←→COMP. YES En-23
D-SUB INPUT RGB — En-23
RGB SELECT AUTO YES En-23
HD SELECT 1080B/1035I/1080A NO En-24
INPUT SKIP OFF←→ON YES En-24
ALL RESET OFF←→ON — En-24
:Shaded areas indicate the default value.
מ←→ם
: Press the
ᮤ
or
ᮣ
button to adjust.
:Menu items in a ruled box are available when the ADVANCED OSM is set to ON.
Menu Tree
* For further details of each menu item, please refer to the CD-ROM.
