Start up Guide
(Enhanced split screen Model)
For the operation of your plasma monitor, refer to the CD-ROM.
Contents
Important Information.................................. En-2
Installation .................................................. En-4
Ventilation Requirements for enclosure mounting ......En-4
Creating a video wall ...........................................En-5
Cable Management..............................................En-5
Caution when placing the plasma monitor in portrait
mode ..............................................................En-6
Using the remote control .......................................En-6
Battery Installation and Replacement ..................... En-6
Using the wired remote control mode .................... En-6
Operating Range .................................................... En-6
Handling the remote control................................... En-6
Part Names and Function .............................. En-7
Front View ..........................................................En-7
Rear View/ Terminal Board ................................... En-8
Remote Control ....................................................En-9
Basic Operations......................................... En-10
POWER ............................................................En-10
To turn the unit ON and OFF: .............................. En-10
VOLUME ..........................................................En-10
To adjust the sound volume:................................. En-10
MUTE ............................................................... En-10
To mute the audio: ............................................... En-10
DISPLAY ............................................................ En-10
To check the settings: ........................................... En-10
DIGITAL ZOOM .................................................En-10
AUTO ADJUST .................................................. En-10
To adjust the size or quality of the picture automatically: ....
En-10
OFF TIMER ........................................................ En-10
To set the off timer: .............................................. En-10
To check the remaining time: ............................... En-10
To cancel the off timer: ........................................ En-10
OSM (On Screen Menu) Controls ................... En-11
Menu Operations ...............................................En-11
Menu Tree ......................................................... En-12
Troubleshooting.......................................... En-14
Specifications ............................................. En-15
Limited Warranty Plasma Monitors.............................. En-16
User’s Manual on CD-ROM
ⅷThe complete user’s manual is supplied on the CD-ROM in
PDF (Portable Document Format) and provides detailed
product and useage information for your NEC plasma monitor.
You must have Adobe Acrobat Reader™ or Adobe Reader™
in order to view and/or print the PDF files.
NOTE:
Adobe Acrobat Reader or Adobe Reader can be
downloaded from Adobe’s website.
Visit http://www.adobe.com and obtain the current version for
your OS.
ⅷViewing the User’s Manual (PDF)
[Windows]
1. Insert the supplied CD-ROM in your computer’s CD-ROM drive.
2. A menu should be displayed automatically.
If this does not happen:
1) On the Windows desktop, double-click the [My Computer] icon.
2)Double-click the [NECPLASMA-UM] CD-ROM drive letter.
3)Double-click the “start_menu.pdf”.
3. Click your product name.
The user’s manual will be displayed on the screen.
[Macintosh]
1. Insert the supplied CD-ROM in your Macintosh’s CD-ROM drive.
2. Double-click the [NECPLASMA-UM] CD-ROM icon.
3. Double-click the “start_menu.pdf”.
The Start Menu will be shown.
4. Click your product name.
The user’s manual will be displayed on the screen.
ⅷCopying the User’s Manual (PDF) to your computer
The user’s manual on the supplied CD-ROM can be copied
onto your computer’s hard drive.
ENGLISH
Contents of the Package
Ⅺ Plasma monitor
Ⅺ Power cord
Ⅺ Remote control with two AAA Batteries
Ⅺ Manuals (Start up Guide and CD-ROM)
Ⅺ Ferrite cores
Ⅺ Cable clamps
Options
• Wall mount unit
• Ceiling mount unit
• Tilt mount unit
• Tabletop Stand
• Attachable speakers
