1A23
Connections
1 Use a standard antenna cable to connect the wall jack to the ANT. IN jack on STB.
2 Connect a coaxial digital audio cable (purchase locally) from DIGITAL AUDIO (COAXIAL) output jack
on STB to a coaxial digital audio input jack on the digital decoder.
3 Connect STB and the TV with a video cable.
NOTE:
Refer to the pages describing the connection to TV for connecting to the TV.
4 Set the video resolution selection switch to “1080i.”
NOTE:
For the capability of your TV and further information, refer to TV owner’s manual.
5 Plug the AC power cord of the decoder into an AC outlet, then turn the decoder on.
6 Set the decoder to the input mode.
NOTE:
Refer to the decoder owner's manual for further information.
7 Plug the AC power cord of STB into an AC outlet, then turn them on.
NOTE:
STB will output the sound from the DIGITAL AUDIO (COAXIAL) output only when receiving a digital
broadcast.
Dolby® information:
Manufactured under license from Dolby Laboratories. "Dolby" and the double-D symbol are registered
trademarks of Dolby Laboratories Licensing Corp. Confidential unpublished works. ©1992-1997 Dolby
Laboratories. All rights reserved.
