1 Power Button Toggles the DVD into and out of Standby Standby Indicator will glow Red
2 Eject Button Opens and Closes the disc loading tray Display will indicate OPEN/CLOSE
3 Setup Button OSD displays the Setup Menu See Setup
4 Title/Menu Button Displays DVD Disc Menu
5 Brief Button Briefly plays and Displays directly accessible Titles PBC OFF
6 PBC Button Toggles broadcast On and Off
7 Zoom Button Displays picture in normal to x2, x4, normal, x2, x4 ….. zoom
8 Slow Button Displays picture in normal, SF x2, x4 ,x8 SR x2, x4, x8, normal
9 Goto Button During Play allows selection of desired Title or Chapter
Use < or > to select
TiTle or Chapter
Entre No. using Numercal keys
10 Scan Button Scans Reverse x2, x4, x8, x16, x32, normal Fast reverse on CDs
11 Scan Button Scans Forward x2, x4, x8, x16, x32, normal
Fast forward on CDs
12 Skip Button Skips Back one Title at a time Skips back a track on CDs
13 Up Button Moves Cursor Up
14 Skip Button Skips Forward one Title at a time
Skips forward a track on CDs
15 Move Right Button Moves Cursor Right
16 Move Left Button Moves Cursor Left
17 Pause/Step Button Pauses picture and evry time moves it forward a frame
Press Play/SEL. to resume
18 Stop Button Stops play Press Play/SEL. to resume on DVDs
19 Move Down Button Moves Cursor Down
20 Display Button Displays Time elapsed, remaining on Title and Chapter Track and Disc for CDs
21 Audio Button Selects Audio outputs available on DVD disc
22 Subtitle Button Selects Subtiles available on DVD disc
23 Angle Button Selects camera angles available on DVD disc
24 A-B Repeat Button Selects points A and B on disc for repeat to commence and end
Press during play at the point where repeat is to commence
Press again at the point where repeat is to be concluded
25 1/ALL Repeat Button Selects Chapter or Title to be repeated Press during play
Repeat of chapter being played
Repeat of Title beaing played
Cancel repeat mode
26 Clear Button Erases in sequence from last programmed Track
Every press erases one programmed track
27 Memory Button Programmes Tracks to be played in the order desired Press Stop
Press Memory
Use numerical keys to enter Numbers
Press Play/SEL.
28 Numerical Buttons Selects the desired numbers 001 for 1, 002 for 2 …etc.
29 Volume Button Adjusts L&R Audio Output Volume
Not applicable to Digital Output
30 TV/System Button Selects between Multi, NTSC or PAL Video Output systems During Play
31 Mute Mutes and unmutes Audio Output
In all modes
Roksan Audio ltd Caspian DVD Player User Manual
CLASSIFICATION: General Use Version 2.01
All specifications are liable to change without notice. E&OE Page 9 of 22 ENGLISH
Direct Access via Numerical Buttons:
You can access your desired track on a CD directly by entering the desired track number (001 for 1, 002
for 2 … etc.) The DVD player would automatically go to the selected track on the CD and begin to play.
If you do not enter the preceding zeros, then press PLAY/SEL. or wait after you have entered the track
number, and your selected track starts to play after a few seconds.
When playing CDs, the DVD front panel display will indicate the track number for a couple of seconds and
then the display will revert to showing elapsed time. (The OSD will indicate your selections such as Track
Number, Play, Pause, Scan etc)
On DVDs, you can access your desired Title/Chapter, by first selecting ‘GOTO’, then select between Title
or Chapter and then enter the desired number as outlined above (01 for 1, 02 for 2 … etc).
