Connections
TV and Cable Box
Some cable TV systems use scrambled or encoded signals that require a cable box to view all
channels. If you subscribe to such type of service, use this connection.
1 Connect the coaxial cable from your cable service to the IN jack on your cable box.
2 Connect a coaxial cable (not supplied) from the OUT jack on your cable box to the
VHF/UHF jack on your TV.
Using your TV with this connection
❏ Program your Sony remote control to operate your cable box (see page 5).
❏ To activate your remote, press (FUNCTION button) to operate your cable box. Then
use
buttons or CH+/- buttons to change the channels. In order to do this, first
program your remote control, then use the Channel Fix feature to set your TV to channel 3
or 4 (see page 31).
VIDEO
LINE
OUT
AUDIO L AUDIO R
1
3
4
VIDEO
L
(MONO)
R
S VIDEO
Y
P B
P R
L
R
1
2
Rear of TV
Cable box
From cable/
antenna
