Other Information
Specifications
For all models (except as noted)
Design and specifications are subject to change without notice.
Television system American TV standard/NTSC
Channel coverage VHF: 2-13/UHF: 14-69/CATV: 1-125
Antenna 75-ohm external antenna terminal for VHF/UHF
Picture tube FD Trinitron
®
tube
Power requirements 120V, 60 Hz
Supplied accessories Size AA (R6) batteries (2)
Remote Control RM-Y195 (1)
Inputs/outputs Inputs 1 video, 1 audio (front) Outputs
2 video, 2 audio (rear) 1 AUDIO OUT
1 S VIDEO
1 RF
1 Y, PB, PR, 1 audio
Optional accessories TV Stand: SU-32FS2 for KV-32FS120
SU-36FS2 for KV-36FS120
KV-32FS120
Screen size Visible screen size: 803 mm (32 inches) measured diagonally
Actual screen size: 863.6 mm (34 inches) measured diagonally
Speaker output 10 W x 2
Power consumption 175 W
Less than 1 W in standby
Dimensions (W/H/D)
898 x 696 x 576 mm (35
3
/
8
x 27
3
/
8
x 22
5
/
8
inches)
Mass 75 kg (165 lbs. 6 oz.)
KV-36FS120
Screen size Visible screen size: 911 mm (36 inches) measured diagonally
Actual screen size: 965.2 mm (38 inches) measured diagonally
Speaker output 10 W x 2
Power consumption 180 W
Less than 1 W in standby
Dimensions (W/H/D)
985 x 774 x 633 mm (38
3
/
4
x 30
1
/
2
x 24
7
/
8
inches)
Mass 98.4 kg (216 lbs. 15 oz.)
