Optional suspended mount using eye bolts
Note: When the suspended installation option is ordered, eye bolts are
supplied.
1. Remove the cap screw on the top side of the case (furthest from
the end plate). Install the eye bolt into the internally threaded nut
from which you removed the cap screw. Repeat the procedure to
install the eye bolt on the opposite end of the case.
2. Suspend the unit from the eye bolts on the unit using chains,
cables, Unistrut, threaded rod, or turnbuckles. Refer to Figure 3.
3. Make sure the unit is level, from front to back and from left to
right.
Luxus Communicator: Owner’s Manual 5
Figure 3. Suspended mount
