9 Technical Data
DBS-Tuner:
Input frequency range 950….2150 MHz
Input level range -65 dBm… -25dBm
Noise max 12 dB
DBS tuner input F-connector
Input impedance 75 Ohm
AFC capture range +/- 3 MHz
Demodulation Shaped QPSK
Symbol rate 2….45 Mbaud/s, SCPC/MCPC compatible
FEC concatenated Viterbi and Reed-Solomon
Viterbi rates 1/2, 2/3, 3/4, 5/6, 7/8 and automatic detection (K=7)
Roll-off factor 35 %
Demultiplexing: in accordance with ISO 13818-1
Card reader:
Type Single slot card reader
Function Card reader for embedded IRDETO
Video decoding:
Video compression Compatible with MPEG-1 and MPEG-2
Up to MP@ ML (main profile @ main level)
Format PAL / SECAM (25Hz)
Active image area 720 pixels x 576 lines
Picture formats 4:3 / 16:9
Picture input 16:9 Automatic
Letterbox filtering for 4:3 TV sets
Audio decoding:
Audio compression MPEG-1 and MPEG-2 Layer I and II
Audio mode Dual (main/sub), stereo
Sampling frequencies 32 kHz, 44.1 kHz, 48 kHz
Audio parameter:
Analogue output:
Output level L/R 0.5 V RMS (nominal)
Output impedance 600 Ohm
THD >60 dB (1 kHz)
Crosstalk < - 65 dB
Analogue input:
Input level L/R 0.5 V RMS (nominal)
Input impedance > 40 kOhm
Volume at Switch-on Automatic use of previous volume setting
Video parameters:
Input:
Input level CVBS 1 Vs-s +/- 0.3 dB into 75 Ohm
Input level RED 0.7 Vs-s +/- 0.1 Vp-p into 75 Ohm
Input level GREEN 0.7 Vs-s +/- 0.1 Vp-p into 75 Ohm
Input level BLUE 0.7 Vs-s +/- 0.1 Vp-p into 75 Ohm
42
