2.4 Connecting up your digital receiver 11
7
HDMI
Audio and video output socket for the high defini-
tion television set.
8
S-VIDEO
Super video output socket for the television
set.
9
TV Audio and video output socket for the television set.
10
VCR
Audio and video input/output socket for the video
cassette recorder or suchlike.
11
USB USB port for firmware update and data transfer.
12
S/PDIF
Dolby digital output socket for the audio system.
13
RS-232
Serial port for firmware update and data transfer.
Table 2.3: Connectors specifications
HDMI High definition video output
Left & right audio output
Dolby digital audio output
VIDEO Composite video (CVBS) output
AUDIO Left & right audio output
S-VIDEO Super video (S-Video) output
TV CVBS/S-Video/RGB/YUV video output
Left & right audio output
VCR CVBS video output
Left & right audio output
CVBS/S-Video/RGB/YUV video input for bypass
Left & right audio input for bypass
S/PDIF Dolby digital audio output
RS-232 115.2kbps at maximum
USB 2.0 device
2.4 Connecting up your digital receiver
There are several ways to set up the digital receiver. Set up the
digital receiver suitably to your television and other appliances.
If you have any problem with your setup or need help, contact
your dealer.
