1-8 Chapter 1: Hardware information
1.5.4 Layout contents
Slots Page
1. DDR2 DIMM slots 1-15
2. PCI slots 1-19
3. PCI Express x 1 slots 1-20
4. PCI Express x16 slots 1-20
Jumpers Page
1. Clear RTC RAM (3-pin CLRTC1) 1-21
2. USB Power (3-pin USBPW12, 34, 56, 78) 1-23
3. Password Skip (3-pin PASSWORD_s) 1-22
4. BIOS Recovery (3-pin BIOS_R) 1-22
Rear panel connectors Page
1. Serial (COM1) port 1-25
2. VGA port 1-25
3. S/PDIF Out port 1-25
4. LAN (RJ-45) port. 1-24
5. IEEE 1394a port. 1-24
6. USB 2.0 ports 1 and 2, 3 and 4 1-25
7. Center/Subwoofer port (orange) 1-24
8. Rear Speaker Out port (black) 1-24
9. Line In port (light blue) 1-24
10. Line Out port (lime) 1-24
11. Microphone port (pink) 1-24
12. Side Speaker Out port (grey) 1-24
Internal connectors Page
1. Floppy disk drive connector (34-1 pin FLOPPY) 1-25
2. IDE connector (40-1 pin PRI_IDE) 1-26
3. Serial ATA connectors (7-pin SATA1, SATA2, SATA3, SATA4) 1-27
5. USB connectors (10-1 pin USB56, USB78) 1-29
6. IEEE 1394a port connector (10-1 pin IE1394_2) 1-30
7. CPU and chassis fan connectors
(4-pin CPU_FAN, 4-pin CHA_FAN1)
1-28
8. ATX power connectors (24-pin EATXPWR, 4-pin EATX12V) 1-28
9. Front panel audio connector (10-1 pin F_AUDIO1) 1-30
10. Internal audio connector (4-pin AUX1) 1-29
11. Digital audio connector (3-pin SPDIF_OUT) 1-27
12. System panel connector (10-1 pin F_PANEL1)
•
System power LED (Green 2-pin PWR_LED)
•
Hard disk drive activity LED (Red 2-pin HD_LED)
•
ATX power button/soft-off button (Black 2-pin PWR_BTN)
•
Reset button (Blue 2-pin RESET)
1-31
