2-20 Chapter 2: BIOS setup
Select Menu
Item Specific Help
Phoenix-Award BIOS CMOS Setup Utility
Advanced
South OnChip IDE Device
This sub-menu contains IDE function-related items. Select an item then
press <Enter> to edit.
South OnChip IDE Device
IDE DMA transfer access [Enabled]
OnChip IDE Channel0 [Enabled]
IDE Prefetch Mode [Disabled]
F1:Help ↑↓ : Select Item -/+: Change Value F5: Setup Defaults
ESC: Exit →←: Select Menu Enter: Select Sub-menu F10: Save and Exit
Select Menu
Item Specific Help
Onboard Device Configuration
South OnChip IDE Device
Onboard 1394 Controller [Enabled]
Onboard LAN [Enabled]
Onboard LAN Boot ROM [Disabled]
South OnChip PCI Device
Onboard SATA Type [IDE Controller]
Init Display First [PCIEx]
x Surroundview Disabled
Serial Port1 Address [3F8/IRQ4]
MODEM Use IRQ [3]
USB Configuration
Phoenix-Award BIOS CMOS Setup Utility
Advanced
2.4.4 Onboard Device Configuration
OnChip IDE Channel0 [Enabled]
Allows you to enable or disable the onchip IDE channel 0 controller .
Configuration options: [Disabled] [Enabled]
IDE DMA transfer access [Enabled]
Allows you to enable or disable the IDE DMA transfer access.
Configuration options: [Disabled] [Enabled]
IDE Prefetch Mode [Disabled]
Allows you to enable or disable the IDE PIO read prefetch mode.
Configuration options: [Disabled] [Enabled]
