Geberit Tessera
TM
Toilet System
Installation & Maintenance Instructions
PRODUCT OVERVIEW
The Tessera
TM
in-wall Toilet System uses siphonic action to
get the job done cleanly and effeciently with only 1.6 gal-
lons per flush. The high density polyethylene tank is well
insulated to prevent condensation. The in-wall installation
system has three key advantages. First, the flush tank is in
the wall which minimizes noise levels. Second, the wall-
hung bowl saves up to 9” of space compared to floor-
mounted models. Finally, the toilet base is eliminated
making cleaning underneath quick and easy. The concea-
led tank and carrier ship as a single unit, a fully factory
assembled fixture, ready for fast and easy installation.
The Tessera
TM
in-wall Toilet System consists of:
• Tank & Carrier 111.336.00.1
• Wall Hung Bowl 111.870.XX.1
• Flush Actuator Plate 111.760.XX.1
• Closed Front Toilet Seat 113.050.XX.1
PRODUCT SPECIFICATION
• The 2 bolt bowl complies with ASME A112.19.2 Vitreous
China Plumbing Fixture Standard.
• The carrier has an adjustable height to accommodate
15”-19” (381-483 mm) rim height, per ADA.
• The unit uses 1.6 GPF / 6 LPF.
• Flush actuator plates are die-cast zinc and plated to
preserve the material’s integrity.
• Actuators are available in a wide variety of finishes.
FEATURES
• Steel, powder-coated carrier
• Die-cast zinc actuator:
Dim. 9-5/8” (245 mm) wide; 6-1/2” (165 mm) high
• 3” DWV discharge connection
• Carrier adjustable range from15”-19” (381-483 mm)
bowl height
• Water consumtion 1.6 GPF / 6 LPF
• Easy cleaning of surrounding areas
• Tank insulated to prevent condensation
IN COMPLIANCE WITH
- ASME 112.19.2
- ASME 112.6.2
- CSA B125
- ASSE 1002
AVAILABLE OPTIONS
• White wall-hung bowl 111.870.DY.1
• Bone wall-hung bowl 111.870.AA.1
• Biscuit wall-hung bowl 111.870.FF.1
• White closed front seat 113.050.DY.1
• Bone closed front seat 113.050.AA.1
• Biscuit closed front seat 113.050.FF.1
• Tile cushion pad 156.055.00.1
• Remote Flush Actuator 115.941.XX.1
• Access panel (drywall) 115.767.11.1
• Access panel kit (tile/marble) 461.043.00.1
HOW TO ORDER
Contact your local Geberit dealer or visit our website for
more information at www.us.geberit.com
TECHNICAL SUPPORT
For additional technical assistance call 1-800-832-8783 or 1-
800-225-7217, or visit our webside at www.us.geberit.com
• Actuators available in a variety of finishes:
- Polished Chrome .21
- Satin Chrome .GH
- PVD Polished Brass .GG
- Satin Brass .CH
- PVD Polished Nickel .IB
- PVD Brushed Nickel .ID
- Pewter .98
- PVD Oil Rubbed Bronze .HM
- Polished Brass/Chrome .GL
- White .11
- Biscuit .FF
- Bone .AA
INSTALLATION REQUIREMENTS
• Tank and carrier system shall be placed within standard
2”x6” (minimum) wall studs (wood or metal) placed with
19
3
/4” (500 mm) clearance.
• For use on Installations with vertical discharge only.
DO NOT CUT DISCHARGE PIPE.
• 3” DWV vertical waste line connection.
• Water supply shall be
1
/2” copper, recommended water
pressure from 25 PSI to 90 PSI.
• Materials suitable for wall construction include Gypsum-
green board, cement board, or tile backer board. Wall
thickness not to exceed 2”.
• When installing remote actuator, use of access panel kit
(461.043.00.1 or 115.767.11.1) is recommended.
• When mounting bowl on tile or marble, use of a tile
cushion pad (156.055.00.1) is recommended.
• All installations must conform to local and national
plumbing, building and fire codes.
