1. Remove the plugs form the fill and discharge ope
nings of tank & carrier assembly.
2. Install the bowl inlet adapter and discharge adapter
fully into their respective opening.
3. Assemble the gaskets onto the inlet adapter and
discharge adapter.
4. Place a straight edge flush against the wall and
across the fill pipe and mark dimension A. Repeat
for discharge adaper.
5. Remove inlet and discharge adapters from tank &
carrier assembly.
1. Install the inlet and discharge adapters, with
gaskets, fully into the bowl.
2. Measure and mark dimension B on both pipes.
3. Remove pipes and gaskets from bowl.
1. Add dimensions A and B, then subtract
1
/8” to get
dimension C.
2. Use the C dimension and mark a line on each pipe,
measuring from the gasket side.
3. Cut off the excess on the spigot side of each pipe.
