C2657M-A (7/08) 8
< or , (comma)
> or . (period)
Shuttle (outer ring)
Keyboard: Press < or , (comma) for fast rewind. Press > or .
(period) for fast-forward.
Control pad: Turn the shuttle counterclockwise for fast rewind,
clockwise for fast-forward. To increase speed, turn the shuttle
farther in the desired direction.
Shift + < or , (comma)
Shift + > or . (period)
Enter/Shift
Play/pause
Shuttle (outer ring)
Keyboard: Press the Shift key while repeatedly pressing < or ,
(comma). Press > or . (period) to rewind or fast-forward to lock in
the current speed (2x, 4x, 15x, 60x, or 300x). Press P to cancel the
speed setting.
Control pad: Press Enter/Shift while using the shuttle to rewind
or fast-forward to lock in the current speed (2x, 4x, 15x, 60x, or
300x). Press “Play/pause” or turn the shuttle to cancel the speed
setting.
L Go to live
Press L or “Go to live” to switch from viewing recorded video to
viewing live video from the currently selected camera.
S Quick Search
Keyboard: Press S to open the Quick Search dialog box.
Control pad: Press and hold “Quick Search” for 3 seconds to
open the Quick Search dialog box.
P Play/pause
Press P or “Play/pause” to toggle between play back and pause.
You can press this button while viewing live video.
Ctrl + Left arrow,
Ctrl + Right arrow
Enter/Shift +
Jog (inner dial)
Keyboard: Press Ctrl plus the left or right arrow to turn the
volume up or down.
Control pad: Press and hold Enter/Shift while turning the jog
(inner dial) to adjust the volume.
R N/A Starts or stops recording in the currently selected video pane.
Print Scrn
Menu + Green function +
Green function
Captures a snapshot (still video image) and saves it to a USB
memory device.
Table B. Live and Playback Controls (2 of 2)
Keyboard Control Pad Function
