94
manual valves
EPDM Seals
PTFE Seats
3
/8” 12.0674 73.56
1
/2” 12.0676 73.56
3
/4” 12.0671 76.21
1” 12.0657 76.20
1
1
/4” 12.0778 112.28
1
1
/2” 12.0773 113.23
2” 12.0775 141.25
16 12.0667 73.56
20 12.0669 73.56
25 12.1831 76.21
32 12.0307 76.21
40 12.0767 112.28
50 12.0768 113.23
63 12.0769 141.25
FPM Seals
PTFE Seats
16 12.0625 55.53
20 12.0627 55.53
25 12.1816 56.50
32 12.1774 56.50
40 12.2714 86.68
50 12.2715 86.68
63 12.2716 108.79
EPDM Seals
PTFE Seats
FPM Seals
PTFE Seats
Praher Type S4 T-Port Ball Valve
3
/8” 12.0629 55.53
1
/2” 12.0631 55.53
3
/4” 12.2995 56.50
1” 12.2195 56.50
1
1
/4” 12.2997 86.68
1
1
/2” 12.2752 86.68
2” 12.2754 108.79
Description: In-line horizontal T-port 3-way ball valve with lockable handle and
union ends
Mounting: In any position
Maximum Fluid Pressure at 20˚C: 16 bar
Fluid Temperature Range: 0˚C-60˚C
Construction:
Body: PVC-U
Seals: EPDM or FPM
Seats: PTFE
End Connections: Solvent Sockets, BSP Female Thread, HDPE Fusion Spigots
Option: Silicon-free
Inch Solvent Cement Unions Inch Solvent Cement Unions
MM Solvent Cement UnionsMM Solvent Cement Unions
EPDM Seals
PTFE Seats
3
/8” 12.0634 65.34
1
/2” 12.0636 65.34
3
/4” 12.0638 66.59
1” 12.1815 66.59
1
1
/4” 12.0939 99.95
1
1
/2” 12.0940 101.44
2” 12.0941 132.80
BSP Threaded Sockets
1
/2 H0 TKE 102 63.87
3
/4 H0 TKE 103 73.88
1 H0 TKE 104 91.00
1
1
/4 H0 TKE 105 102.25
1
1
/2 H0 TKE 106 124.93
2 H0 TKE 107 162.26
Inch Solvent Cement Sockets
EPDM Seals
PTFE Seats
Durapipe TK 3-Way Ball Valve T-Port
Description: In-line horzontal T-Port 3-way ball valve
Mounting: In any position
Maximum Fluid Pressure at 20˚C: 16 bar
Fluid Temperature Range: 0ºC - 60ºC
Construction:
Body: PVC-U
Seals: EPDM or FPM
Seats: PTFE
End Connections: Solvent Sockets
Options: L-Port; electric or pneumatic actuation
20 H0 TKE 306 63.87
25 H0 TKE 307 73.88
32 H0 TKE 308 91.00
40 H0 TKE 309 102.25
50 H0 TKE 310 124.93
63 H0 TKE 311 162.26
MM Solvent Cement Sockets
EPDM Seals
PTFE Seats
1
/2 H0 TKP 102 83.02
3
/4 H0 TKP 103 97.41
1 H0 TKP 104 118.07
1
1
/4 H0 TKP 105 130.37
1
1
/2 H0 TKP 106 226.33
2 H0 TKP 107 283.45
Inch Solvent Cement Sockets
FPM Seals
PTFE Seats
20 H0 TKP 306 83.02
25 H0 TKP 307 97.41
32 H0 TKP 308 118.07
40 H0 TKP 309 130.37
50 H0 TKP 310 226.33
63 H0 TKP 311 283.45
MM Solvent Cement Sockets
FPM Seals
PTFE Seats
