110
manual valves
Inch or mm Solvent Cement Sockets
Valterra Slide Gate Valve
Description: In-line manually operated slide gate valve
Mounting: In any position
Maximum Fluid Pressure at 20˚C: 1
1
/
2
”/50mm - 3.4 bar; 2”/63mm - 2.5 bar;
3”/90mm - 2 bar; 4”/110mm -1.4 bar; 6” & 8” - 1 bar
Fluid Temperature Range: 0˚C-40˚C
Construction:
Body: ABS or PVC-U
Seals: Santopreme
Paddle: Polypropylene or Stainless Steel
End Connections: Solvent Socket, Solvent Spigot, NPT Threaded
1
1
/2” Socket x Socket Black ABS ABS Polypropylene Plastic I7101 12.14
1
1
/2” Socket x Socket White ABS PVC-U Polypropylene Plastic I6101 12.14
50mm Socket x Socket Grey PVC-U PVC-U Polypropylene Plastic I8101 12.14
2” Socket x Socket Black ABS ABS Polypropylene Plastic I7201 17.63
2” Socket x Socket White ABS PVC-U Polypropylene Plastic I6201 17.63
2” Socket x Socket Black ABS ABS Stainless Steel Plastic I5201 26.10
63mm Socket x Socket Grey PVC-U PVC-U Polypropylene Plastic I8201 17.63
3” Socket x Socket Black ABS ABS Polypropylene Plastic I7301 23.01
3” Socket x Socket White ABS PVC-U Polypropylene Plastic I6301 23.01
3” Socket x Socket Black ABS ABS Stainless Steel Plastic I5301 31.37
90mm Socket x Socket Grey PVC-U PVC-U Polypropylene Plastic I8301 23.01
4” Socket x Socket Grey PVC-U PVC-U Stainless Steel Metal I6401 86.43
110mm Socket x Socket Grey PVC-U PVC-U Polypropylene Plastic I8401 86.43
6” Socket x Socket White PVC-U PVC-U Stainless Steel Metal I6601 327.41
160mm Socket x Socket White PVC-U PVC-U Stainless Steel Metal I8601 327.41
8” Socket x Socket White PVC-U PVC-U Stainless Steel Metal I6801 447.62
Size Connections Colour Body Sockets Paddle Handle Code Price
The Valterra Slide Gate Valve is a simple “pull to
open, push to close” valve designed for low
pressure applications. In addition to the valve, a
range of optional end connections and fittings is
also available. Please enquire for details.
Low Cost Flow Control
Ball Float Valve
1
/2 03500102 23.50
1 03500104 94.00
1
1
/2 03500106 118.00
Description: Liquid level control valve
Mounting: In a horizontal position
Maximum Fluid Pressure at 20˚C: 10 bar
Fluid Temperature Range: 0˚C-60˚C
Construction:
Body: Polypropylene
Arm: Polypropylene
Float: Polypropylene
End Connections: BSP male threaded
economy gate valves
