84
manual valves
inch and mm sizes
Praher Type S4 Ball Valve with Actuator Adaptor Kit
Praher Valve Bracket for Type S4 Ball Valve
3
/8” 122.171 85.47
1
/2” 122.172 87.03
3
/4” 122.173 94.72
1” 122.174 105.78
1
1
/4” 122.175 139.43
1
1
/2” 122.176 153.27
2” 122.177 170.10
2
1
/2” 122.359 285.49
3” 122.761 333.57
4” 122.762 406.29
EPDM Seals
Size Code Price
16 122.357 85.47
20 122.358 87.03
25 122.256 94.72
32 122.238 105.78
40 122.237 139.43
50 122.257 153.27
63 122.898 170.10
75 122.359 285.48
90 122.258 333.57
110 122.360 406.29
16 125.449 85.47
20 125.450 87.03
25 125.451 94.72
32 122.804 105.78
40 125.235 139.43
50 125.452 153.27
63 125.453 170.10
75 125.381 285.49
90 122.263 333.57
110
on application
3
/8” 120.832 85.47
1
/2” 120.833 87.03
3
/4” 120.834 94.72
1” 120.835 105.78
1
1
/4” 120.836 139.43
1
1
/2” 120.837 153.27
2” 120.838 170.10
2
1
/2” 120.839 285.49
3” 120.840 333.57
4” 120.841 406.29
FPM Seals
Size Code Price
Prices on request for BSP threaded sockets or PN10 flanged connections
Includes:
PVC-U Ball Valve,
PVC-U Valve Bracket,
Console, Actuator
Adaptor, Screw Set,
PVDF Shaft
3
/8”/16 170.276 18.40
1
/2”/20 170.276 18.40
3
/4”/25 170.277 19.60
1”/32 170.278 20.80
1
1
/4”/40 170.229 22.12
1
1
/2”/50 170.231 23.45
2”/63 170.233 24.76
2
1
/2”/75 170.266 35.94
3”/90 170.267 40.15
4”/110 170.267 40.15
Size Code Price
Includes:
PVC-U Valve Bracket,
Screws and Nuts
Actuator Mounting Dimensions
Size OD mm 20 25 32 40 50 63 75 90 110
Size DN mm 15 20 25 32 40 50 65 80 80
Size NB inches
1
/2
3
/4 11
1
/4 1
1
/2 22
1
/2 34
A mm 60,0 60,0 60,0 94,0 94,0 94,0 95,0 95,0 95,0
B mm 70,0 70,0 70,0 93,0 93,0 93,0 119,0 119,0 119,0
F mm 11,0 11,0 11,0 14,0 14,0 14,0 17,0 17,0 17,0
R mm 42,0 42,0 42,0 50,0 50,0 50,0 70,0 70,0 70,0
X mm 38,0 38,0 38,0 48,0 48,0 48,0 72,5 72,5 72,5
Y mm 11,0 11,0 11,0 13,0 13,0 13,0 18,0 18,0 18,0
Type F04 F04 F04 F05 F05 F05 F07 F07 F07
A
Y
F
øD
B
G
X
