57
9-5. Search and Playback Viewer
The search window can be accessed by clicking the search icon on the upper right of the main
user interface.
Figure 9.5.1. Main user interface
Table 9.5.1. Main controls in Search
No Button Description
1 DATE & TIME
Displays the recording time of the data selected on the time bar at
the bottom of the main user interface.
2 LIVE
Click this icon to see live video.
3 CAPTURE
Click this icon to capture a still image of recorded video.
Once the capture icon is clicked, this pop up window appears.
The still image is captured in either jpeg or bmp file format.
4 MARK IN
Click this icon to set the start time for video backup.
5 MARK OUT
Click this icon to set the ending time for video backup.
