· TKIP - Unicast (point-to-point) transmissions are en-
crypted using TKIP, and multicast (broadcast)
transmissions are not encrypted.
· TKIP + 64 bit WEP - Unicast (point-to-point) transmis-
sions are encrypted using TKIP, and multicast
(broadcast) transmissions are encrypted using 64 bit
WEP.
· TKIP + 128 bit WEP - Unicast (point-to-point) trans-
missions are encrypted using TKIP, and multicast
(broadcast) transmissions are encrypted using 128 bit
WEP.
· AES - CCMP - CCMP is the most common sub-type of
AES (Advanced Encryption System). Most systems will
simply say "AES". If selected, both Unicast (point-to-
point) and multicast (broadcast) transmissions are en-
crypted using AES.
· AES – CCMP + TKIP - If selected, Unicast (point-to-
point) uses AES-CCMP and multicast (broadcast)
transmissions are encrypted using TKIP.
Group Key Update
This refers to the key used for broadcast transmissions.
Enable this if you want the keys to be updated regularly.
Key Lifetime
This field determines how often the Group key is dynami-
cally updated. Enter the desired value.
Update Group key
when any member-
ship terminates
If enabled, the Group key will be updated whenever any
member leaves the group or disassociates from the WAP-
4060PE.
Radius MAC
Authentication
The current status is displayed. This will always be "Dis-
abled", because Radius MAC Authentication is not available
with WPA-PSK.
UAM
The current status is displayed. This will always be "Dis-
abled", because UAM is not available with WPA-PSK. The
Configure button for this feature will also be disabled.
3.6.8 Security Settings - WPA-802.1x
This version of WPA requires a Radius Server on your LAN to provide the client au-
thentication according to the 802.1x standard. Data transmissions are encrypted using
the WPA standard.
If this option is selected:
· This WAP-4060PE must have a "client login" on the Radius Server.
· Each user must have a "user login" on the Radius Server. Normally, a Certifi-
cate is used to authenticate each user.
· Each user's wireless client must support 802.1x.
· All data transmission is encrypted using the WPA standard. Keys are auto-
matically generated, so no key input is required.
