AP Mode
Both Bridge mode and AP mode can be used simultaneously,
unless AP mode is "Client/Repeater". Select the desired AP
mode:
· None (disable) - Disable AP mode. Use this if you want this
WAP-4060PE to act as Bridge only.
· Access Point - operate as a normal Access Point
· Client/Repeater - act as a client or repeater for another
Access Point. If selected, you must provide the address
(MAC address) of the other AP in the Repeater AP MAC
Address field. In this mode, all traffic is sent to the specified
AP.
Note: If using Client/Repeater mode, you cannot use Bridge
Mode.
Repeater AP
MAC Address
This is not required unless the AP Mode is "Client/Repeater". In
this mode, you must provide the MAC address of the other AP in
this field. You can either enter the MAC address directly, or, if the
other AP is on-line and broadcasting its SSID, you can click the
"Select AP" button and select from a list of available APs.
Broadcast
SSID
If Disabled, no SSID is broadcast.
If enabled, you must select the security profile whose SSID is to
be broadcast. This can be done in the "Security Profiles" screen.
The SSID will then be broadcast to all Wireless Stations. Sta-
tions which have no SSID (or a "null" value) can then adopt the
correct SSID for connections to this Access Point.
Bridge Mode
Both Bridge mode and AP mode can be used simultaneously,
unless AP mode is "Client/Repeater". Select the desired Bridge
mode:
· None (disable) - Disable Bridge mode. Use this if you want
this WAP-4060PE to act as an AP only.
· Point-to-Point Bridge (PTP) - Bridge to a single AP. You
must provide the MAC address of the other AP in the PTP
Bridge AP MAC Address field.
· Point-to-Multi-Point Bridge (PTMP) - Select this only if this
AP is the "Master" for a group of Bridge-mode APs. The
other Bridge-mode APs must be set to Point-to-Point Bridge
mode, using this AP's MAC address. They then send all traf-
fic to this "Master".
If required, you can specify the MAC addresses of the APs
which are allowed to connect to this AP in PTMP mode. To
specify the allowed APs:
1. Enable the checkbox "In PTMP mode, only allow specified
APs".
2. Click the button "Set PTMP APs".
3. On the resulting sub-screen, enter the MAC addresses of
the allowed APs.
PTP Bridge AP
MAC Address
This is not required unless the Bridge Mode is "Point-to-Point
Bridge (PTP)". In this case, you must enter the MAC address of
the other AP in this field.
