English Owner’s Manual
10
VX401E/VZ401E
Shared modes
[VOLUME] Button
Increase or decrease volume.
[MUTE] Button
Turns mute on or off.
[OPEN] Button
Press this button to OPEN or CLOSE the
motorized screen (VZ401E). Please ensure
there are no obstructions before starting the
operation.
[SRC/POWER] Button
• Short press to scroll through the available
sources such as the tuner, DVD player, iPod,
USB modes, etc.
• Long press (over 1 second) to turn off the
unit.
[MENU] Button
Press this button to access the MAIN MENU.
From the main menu, you can select your
desired source or change your settings.
[PIC] Button
Press this button to change monitor Brightness.
[SET] Button
Press this button to access the Audio Settings.
[BACK] Button
Press this button to exit selection and
adjustment menus.
[ENTER] button
Press to fix the chosen or entered data.
TUNER Radio mode
[BAND] button
Press this button to switch reception band.
[0 - 9] Buttons
• Use in the Key Pad screen to set the Radio
channels.
• Use to select the preset number in the Preset
List screen.
[
], [
] Buttons
Press to seek the next available station up or
down in the TUNER Radio mode.
[
], [
] Buttons
Press to manually select the next station up or
down in the TUNER Radio mode.
[
], [
], [
], [
] Buttons
• Press [
], [
] to scroll through the saved
presets list in the TUNER Radio mode.
• Press [
], [
] to scroll through the page
screens in the TUNER Radio mode.
[TA] Button
Press to set TA standby mode on or off.
DVD PLAYER mode
[
/
] Button
• Short press to play or pause the video or
audio media.
• Long press (over 1 second) to stop the video
or audio media.
[SEARCH] Button
Press to open the direct search menu while in
the DVD video mode.
[ENTER] Button
Press to select, play or pause video and audio
media.
[0 - 9] Buttons
• Press to enter DVD video chapters/titles in
the Key Pad screen.
• Press to set the track/folder number of the
CD, or MP3/WMA in the Key Pad screen.
[TITLE] Button
Press to go to the title menu on the DVD.
[ROOT] Button
Press to go to the root menu on the DVD.
[
], [
], [
], [
] Buttons
• Press to select button items on the menu
screen of a DVD video.
• Press [
], [
] to scroll through the pages
creens in the CD and MP3/WMA modes.
Functions of Remote Control Buttons
You can use the remote control unit to control the VX401E and VZ401E.
Note:
•
The wireless remote control operation may not be optimal in direct sunlight.
VX_VZ401E_EN_GE_FR_IT_ES_multibook.indb 10 4.8.2010 22:02:19
