VOLTAGE CHART
14
LOC PIN
MODE
LOC PIN
MODE
ON OFF ON OFF
I701 1 4.86 4.96 I703 1 0 0
2 4.81 4.94 2 0 0
3 5.03 4.97 3 0 0
4 5.03 4.97 4 0 0
5 0 0 5 4.91 4.94
6 1.9 1.87 6 4.86 4.92
7 2.71 2.67 7 0 0
8 4.99 4.91 8 5.01 4.95
9 5.04 4.95
LOC PIN
MODE
10 0 0 ON OFF
11 2.28 0 I801 1 2.47 0
12 0 4.88 2 2.33 1.33
13 4.93 4.87 3 0 0
14 3.71 3.64 4 18.28 9.19
15 2.66 2.44 5 137.2 145
16 0 4.88 6 0.067 0
17 4.96 0.71 7 137.2 145
18 4.07 4.95
19 0 0
20 0 0
21 0 0
22 0 0
23 4.84 4.56
24 0 0
25 0 0
26 0 0
27 0 0.22
28 5.03 4.93
29 4.8 4.7
30 5.05 4.95
31 0 4.88
32 5.05 4.95
33 0 0
34 0 0
35 0 0
36 0 0
