56
ENGLISH
When “7 Digital Audio Output” is Selected
1
2
See page 44.
3
4
Use the • and ª cursor buttons to select “7 Digital Audio Output”, then
press the SELECT button.
1. LPCM 96k
/
48k
To select whether digital audio converted to 48 kHz/16 bit is output
from the optical/coaxial digital audio output connector or no digital audio
is output during playback of the DVD recorded in Linear PCM of 96 kHz.
(In case of the DVD recorded in Linear PCM of 48 kHz, digital audio
converted to 48 kHz/16 bit is output irrespective of the setting.)
2. Dolby Digital
To select the signal format (Bitstream or PCM) to be output from the
optical/coaxial digital audio output connector during playback of the DVD
recorded in Dolby Digital (AC-3).
3. dts
To select whether DTS bitstream is output from the optical/coaxial
digital audio output connector or no digital audio is output during
playback of the DVD recorded in dts.
Use the
• and ª cursor buttons to select the desired setting, then press
the SELECT button.
q When “1 LPCM 96k
/
48k” is selected
1. No (Factory default)
Digital audio of 48 kHz/16 bit is output during playback of the DVD
recorded in Linear PCM of 48 kHz. No digital audio is output during
playback of the DVD recorded in Linear PCM of 96 kHz. However, audio
will be output using the original audio recording system in case of the
DVD which has not been copyright-protected.
2. Yes
During playback of the DVD recorded in Linear PCM of 48 kHz or 96
kHz, digital audio converted to 48 kHz/16 bit is output.
(Digital output of PCM audio is restricted to 48 kHz/16 bit or below for
copyright protection.)
w When “2 Dolby Digital” is selected
1. Bitstream (Factory default) (NOTE 1)
Dolby Digital (AC-3) bitstream (1ch – 5.1ch) is output during playback of
the DVD recorded in the Dolby Digital (AC-3).
Select this setting when the player is connected to the Dolby Digital
(AC-3) decoder.
2. PCM
Digital audio converted to PCM (2ch) of 48 kHz/16 bit is output during
playback of the DVD recorded in the Dolby Digital (AC-3).
Digital Audio Output
1 LPCM 96k 48k No
2 Dolby Digital Bitstream
3 dts Off
0 Exit
Remote control unit
SELECT
Remote control unit
SELECT
Remote control unit
