Hardware
Package contents: hardware
Note: Not all hardware will be used.
Make sure you have all the hardware necessary to assemble your new wall mount:
Label Hardware Qty.
04 4
05 4
06 4
07 4
08 4
09 4
10 4
11 4
12 4
5/16" × 2 3/4" lag bolt
(7.9 mm × 69.9 mm)
5/16" (7.9 mm)
washer
Concrete anchor
M4 × 12 mm screw
M4 × 30 mm
screw
M5 × 12 mm screw
M5 × 30 mm
screw
M6 × 12 mm screw
M6 × 20 mm screw
Label Hardware Qty.
13 4
14 4
15 4
16 4
17 8
18 4
19 4
20 4
M6 × 35 mm
screw
M8 × 16 mm
screw
M8 × 40 mm
screw
M8 × 60 mm screw
M4/M5 washer
M6/M8 washer
M4/M5 spacer
M6/M8 spacer
1 0 20 30 40 50 60 70 80 90 100mm
1234in
