10
a
POWER: Switches the recorder
ON or OFF.
OPEN/CLOSE (Z): Opens and
closes the disc tray.
TV/DVD: To view channels
selected by the recorder tuner or
by the TV tuner.
INPUT: Changes the input to use
for recording (Tuner, AV1-2, or DV
IN).
0-9 numerical buttons: Selects
numbered options in a menu.
I.SKIP (INSTANT SKIP): Skips 30
seconds forward during playback.
TV Control Buttons: See page
48.
b
SCAN (m / M): Search
backward or forward.
SKIP (. / >): Go to next or
previous chapter or track.
PAUSE/STEP (X) : Pause
playback or recording temporarily.
PLAY (N): Starts playback.
STOP (x): Stops playback or
recording.
c
HOME: Accesses or removes the
HOME menu.
MENU/LIST: Accesses menu on a
DVD disc. Switches between Title
List-Original and Title List-Playlist
menu.
b / B / v / V (left/right/up/down):
Selects an option in the menu.
ENTER ( )
Acknowledges menu selection.
CH (+/-): Scans up or down
through memorized channels.
DISPLAY: Accesses On-Screen
Display.
RETURN (O)
Removes the menu.
AUDIO ( ): Selects an audio
language or audio channel.
SUBTITLE ( ): Selects a subtitle
language.
ZOOM: Enlarges DVD video
image.
CHP. ADD: Inserts a chapter
marker when playing/recording.
d
REC (z): Starts recording.
REC MODE: Selects the recording
mode.
TITLE: Displays the disc’s Title
menu, if available.
THUMBNAIL: Selects a thumbnail
picture.
PLAY MODE: Selects a play
mode.
MARKER: Marks any point during
playback.
SEARCH: Displays Marker Search
menu.
CLEAR: Removes a mark on the
Marker Search menu.
TIMESHIFT: To play the title being
recorded and also currently being
recorded appears as PIP.
PIP: Selects PIP function on or off.
RESOLUTION:
Sets the output
resolution for HDMI.
button(s) is not used.
Remote Control
a
b
c
d
Remote Control Operation
Point the Remote Control at the remote sensor and
press the buttons.
Caution
Do not mix old and new batteries. Never mix different
types of batteries (standard, alkaline, etc.).
Remote Control Battery Installation
Remove the battery cover on the
rear of the Remote Control, and
insert two R03 (size AAA)
batteries with and matched
correctly.
