19
Hookup and
Settings
Auto Clock Set
In the Auto option, the Recorder looks for a channel
carrying XDS (Extended Data Services) information.
XDS updates the clock using the Coordinated
Universal Time.
1. Select [Clock set] option then press B.
2. Use v / V to select [Auto] option then press
ENTER.
3. Use v / V / b / B to choose the [Band],
[PBS Ch.], [Time Zone], and [Daylight Savings]
options.
[Band] Choose your TV BAND (TV or CATV).
[PBS Ch.] Choose your local PBS channel.
[Time Zone] Choose your Time Zone manually.
When Timezone is set to Auto, the Recorder will
use XDS information to determine the proper
setting.
[Daylight Savings] Choose Auto, ON, or OFF.
When it is set to Auto, the Recorder will use XDS
information to determine the proper setting.
4. Press ENTER to confirm your setting.
Note :
The Auto Clock Feature enables the Recorder to set
up the clock when the Recorder is turned off.
Manual Clock Set
If your local TV station does not send date and time
information, or sends incorrect information, you can
set the clock manually.
1. Select [Clock set] option then press B.
2. Use v / V to select [Manual] option then press
ENTER.
3. Enter the necessary information for year, date and
time.
b / B (left/right): Moves the cursor to the previous
or next column.
v / V (up/down): Changes the setting at the
current cursor position.
4. Press ENTER to confirm your setting.
TV Aspect
Selects the aspect ratio of the connected TV (4:3
standard or wide).
[4:3 Letter Box] Select this when connecting to a 4:3
screen TV. Displays a wide picture with bands on
the upper and lower portions of the screen.
[4:3 Pan Scan] Select this when connecting to a 4:3
screen TV. Automatically displays a wide picture on
the entire screen and cuts off the portions that do
not fit.
[16:9] Select this when connecting to a wide-screen
TV or TV with a wide mode function.
Power Save Mode
You can set up the unit into an economic power save
mode. Nothing is displayed in the display window
when the unit is turned off.
[OFF] Power Save Mode is not active.
[ON] Power Save Mode is active.
Note:
The Power Save Mode is not available in the standby
mode for the timer recording.
Factory Set
If you need to, you can reset the Recorder to all its
factory settings. Select ‘‘Set’’ icon then press ENTER
and auto setup menu will appear, see page 17.
Note:
Some options can not be reset. (Rating, Password,
and Area Code)
