LOADING CODE LIBRARIES
The HTR 4 can store a dierent library of default NAD codes for each of its Device Selector “pages.”
If the original default library does not control your NAD CD player, tape deck, DVD player, or other
component, follow the procedure below to change the code-library.
Begin by ensuring that the component you wish the HTR 4 to control is plugged in and powered-up
(“on,” not merely in standby). To enter the HTR 4’s Library Mode, simultaneously press-and-hold for 3
seconds both the desired Device Selector key and the [PROGRAM] key, until the Learn LED turns green.
While keeping the HTR 4 pointed toward the component, enter the rst appropriate three-digit
code-library number from the table below. If the component turns o, press [ENTER] to accept that
code-library number and exit the Library Mode. If the component does not turn o, enter the next
three-digit code-library number from the table.
When you enter the correct number the component will turn o; press [ENTER] to accept that code
library number and exit the Library Mode.
NAD-brand component HTR 4 code-library numbers
CD Player (new) 200
CD Player (old) 201
Tape Deck B 400
Tape Deck A 401
T562 600
T550, L55 601
T512, T531, T532 602
T571, T572 602
L56 604
T513, T533 605
SEARCH MODE
If none of the codes from the table, when entered, turns on the component, and if you are quite sure
you have followed the above procedure completely and carefully, you may want to try the “search”
method as follows:
Enter Library Mode by simultaneously pressing-and-holding for 3 seconds both the desired Device
Selector key and the [PROGRAM] button until the Learn LED turns green. Now press-and-hold the
HTR 4’s [ ] or [ ]) key; the remote will step through all the available codes at a rate of approximately 1
per second.
When the component turns o, immediately release the cursor key; press [ENTER] to accept that code-
library and exit the Library Mode. Try a few commands; should you prove to have stepped past the
needed code-library, re-enter the Library Mode and use the cursor key to step back to it.
NOTE
It is possible that search mode will nd code-libraries that operate, at least partially, some other
brand (non-NAD) components. You may certainly exploit such capabilities as you nd them.
However, since we can only ensure the completeness or accuracy of NAD code-libraries, we cannot
support the HTR 4’s operation with other-brand components.
OPERATION
USING THE HTR 4 REMOTE CONTROL
ENGLISHFRANÇAISDEUTSCHNEDERLANDSESPAÑOLITALIANOРУССКИЙSVENSKA
27
