W415-0676 / 03.14.08
15
TOP FLAME SPREADER
BOTTOM FLAME SPREADER
FIBRE BAFFLES
TOP FIBREBRICKS
TUBE BURNERS
GASKET
LEFT SIDE FIBREBRICK
RIGHT SIDE FIBREBRICK
REAR FIBREBRICKS
GASKET
RIGHT FRONT FIBREBRICK
LEFT FRONT FIBREBRICK
BOTTOM RIGHT FIBREBRICKBOTTOM LEFT FIBREBRICK
BAFFLE SUPPORT
FIGURE 31
If you need to remove the bricks (to lighten the fi replace for ease of
installation, replacement, etc), follow this sequence:
For Firebrick Removal: Remove the ashwell grate. This allows
the four bottom bricks to be removed fi rst.
Slide out the baffl e support bracket from above the front tube.
Reaching above the top fi rebricks and baffl es, lift and tape the bot-
tom fl ame spreader to the top spreader to ease top brick and baffl e
removal and to avoid damaging the fi bre baffl e. Remove the three
front tubes.
Remove the top fi rebrick on the right, then the left fi rebrick. Remove
the baffl es, starting with the right side.
Remove the gasket rope. Check the rope for deterioration and replace
if necessary. Remove the rear bricks (pull the two bricks forward at
the centre, and lift the bottom of the bricks out). Remove the side
bricks (tilt the tops inward).
